Denon AVR-1723 User Manual

79
LEVEL DIAGRAM
LINE IN 0dB
(200mV)
-10dB
-20dB
-40dB
-30dB
+10dB
+20dB
LINE IN
ADC
DSP
DAC
H/P OUT
SPK OUT
NJU72340A
ATT
FRONT
FRONT CHANNEL
PLD
EPM3032A AK4358
AK5358
ADSP21487
-50dB
0dB (200mVrms)
-10dB
-20dB
-40dB
-30dB
+10dB
+20dB
-50dB
+30dB
-10dBFS
0dBFS
-20dBFS
-30dBFS
-40dBFS
-9dB
-27dBFS
AD IN=50mV
ADC
AK5358
DAC
AK4358VQ
-10dBFS
0dBFS
-20dBFS=177Vrms
-30dBFS
-40dBFS
79mVrms
-23.5dBFS(A/D IN)
-20dBFS(DIG. IN)
-35.5dBFS(A/D IN)
-32dBFS(DIG. IN)
SW : NO
FULL SCALE LEVEL=2.0Vrms
+1.07dB -2.5dB
+1dB
+9.5dB
+13dB
+29dB
4.27Vrms/8ohm
277mVrms/33ohm
SPK OUT
H/P OUT
- SW:YES (DIGITAL)
GAIN setting of MASTER VOL 00dB
-
SW:YES (ANALOG)
- SW:NONE (DIGITAL)
- SW:NONE (ANALOG)
(1):Basic OFFSET of VOL=0dB (PREAMPGAIN:+15.5dB)
(2):OFFSET of SW NON
(3):OFFSET of the AD input
-2.5dB
-2.5dB
-2.5dB
-2.5dB
=-2.5dB
=+1dB
=+9.5dB
=+13dB
(1) (2) (3)
MIC IN
GAIN
ADJ.
28.31dB
MIC IN
11.48mVrms
0dBFS=3Vpp=1.06Vrms
SINGLE INPUT
0dBFS=5Vpp=1.77Vrms
DIFF.OUT
PREOUT 150mVrms
H/P OUT
+12dB
+12dB
+3.5dB
+3.5dB
POWERAMP GAIN
AZ4580 MAX.OUTPUT 7.78Vrms
NJU72340 MAX.OUTPUT 3.8Vrms
