Denon AVR-2113 Service Manual

157
PARTS LIST OF PACKING & ACCESSORIES
s
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE: The symbols in the column "Remarks" indicate the following destinations.
1913E3 : U.S.A. & Canada model
2113CIE3 : U.S.A. & Canada model 2113E2 : Europe model 2113E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
1 - set -
2 nsp POLY BAG 6330000240000S 1
3 963116100080S ANTENNA,WIRE E605010140010S 1
4 nsp CARD S.S LIST 577700162001GS 1
5 nsp WARRANTY CARD
1913BKE3,
2113CIBKE3
5727000003004S 1
6 54111076900AD GETTING STARTED 1913BKE3 5707000006710S 1 *
6 54111077000AD GETTING STARTED 2113CIBKE3 5707000006720S 1 *
6 54111077100AD GETTING STARTED 2113BKE2 5707000006730S 1 *
6 54111077300AD GETTING STARTED 2113SPE1C 5707000007020S 1 *
7 35201007500AD DISK CD MANUAL 1913BKE3 6517000000650S 1 *
7 35201007600AD DISK CD MANUAL 2113CIBKE3 6517000000660S 1 *
7 35201007700AD DISK CD MANUAL 2113BKE2 6517000000670S 1 *
7 35201008000AD DISK CD MANUAL 2113SPE1C 6517000000840S 1 *
8 nsp SAFETY INSTRUCTION 5227000002460S 1 *
9 nsp BATTERY,DRY G670001R50240S 2
10 nsp CARD Pass 2113SPE1C 5777000000020S 1
11 30701010400AD REMOCON RC-1167 8300116700010S 1 *
12 nsp PE SHEET 6327040059000S 1
13 963532100230D CUSHION,SNOW 6230213194000S 1 *
14 nsp POLY BAG ACCESSORY 6330210222000S 1
15 32401000800AD MIC CONDENSER ACM1HB M040000310080S 1 *
16 963531102320D BOX,GIFT 1913BKE3 6007212140000S 1 *
16 963531102360S BOX,GIFT 2113CIBKE3 6007212150000S 1 *
16 963531102330D BOX,GIFT 2113BKE2 6007212150010S 1 *
16 963531102350D BOX,GIFT 2113SPE1C 6007212150030S 1 *
17 nsp SHIPPING SUB ASSY E3 5507000007000S 2
18 nsp BUSHING TERMINAL
2113BKE2,
2113SPE1C
2410040353010S 14
19 nsp COLOR LABEL 2113SPE1C 5507020170680S 2
20 nsp WARRANTY CARD 2113SPE1C 5727000000400S 1
z
21 90M-ZC000600R CORD ASSY 2113BKE2 L068250160020S 1

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
