SURROUND MODES AND PARAMETERS
This unit is equipped with a digital signal processing circuit that lets you play program sources in the sound mode to achieve the same sense of presence as in a movie theater. Sound modes and surround parameters This table shows the speakers that can be used in each sound mode and the surround parameters adjustable in each sound mode.
Symbols in the table
S This indicates the audio output channels or surround parameters that can be set. D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.”.
Sound Mode
Channel output Surround Parameter
Front
L/R
Center
Surround
L/R
Surround back L/R
Front height
L/R
Subwoofer Cinema EQ
Loudness
Management
z2
Dynamic
Compression
z3
Low Frequency
Effects
z4
Delay Time
DIRECT/PURE DIRECT (2channel)
z1
S D
z5
S S
DIRECT/PURE DIRECT (Multi-channel)
z1
S D D D
z6
D
z6
D S S S
STEREO
S D S S S
MULTI CH IN
S D D D D
z7
D S
z8
S
DOLBY PRO LOGIC gz S D D D D S S S
DOLBY PRO LOGIC gx S D D D D S
z9
S S
DOLBY PRO LOGIC g S D D D S
z10
S S
DOLBY PRO LOGIC
S D D D S S S
DTS NEO:6
S D D D D S
z7
S S
DOLBY DIGITAL
S D D D D
z7
D S
z8
S
DOLBY DIGITAL Plus
S D D D D
z7
D S
z8
S
DOLBY TrueHD
S D D D D
z7
D S
z8
S S S
DTS SURROUND
S D D D D
z7
D S
z8
S
DTS 96/24
S D D D D
z7
D S
z8
S
DTS-HD
S D D D D
z7
D S
z8
S
DTS Express
S D D D D
z7
D S
z8
S
MULTI CH STEREO
S D D D D D S S S
ROCK ARENA
S D D D D D S S S
JAZZ CLUB
S D D D D D S S S
MONO MOVIE
S D D D D D S S S
VIDEO GAME
S D D D D D S S S
MATRIX
S D D D D D S S S S
VIRTUAL
S D S S S
z1 During playback in PURE DIRECT mode, the surround parameters are the same as in DIRECT mode. z2 This item can be selected when a Dolby TrueHD signal is played. z3 This item can be selected when a Dolby Digital or DTS signal is played. z4 This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is played. z5 Only when “Subwoofer Mode” is set to “LFE+Main”, sound is output from the subwoofer. z6 A signal for each channel contained in an input signal is output as audio. z7 Audio is output from the front height speaker when the set sound mode name contains “+PLgz”. For information on how to check the sound mode. z8 This setting is unavailable when the set sound mode name contains “+PLgx Music”. For information on how to check the sound mode. z9 This setting is possible when the sound mode is “PLgx Cinema” or “DTS NEO:6 Cinema”. z10 This setting is possible when the sound mode is “PLg Cinema”.

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
