Denon AVR-2113 Service Manual

199
VIDEO PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC5000 232810005504S IC BD7628F-E2 J127762800010S
IC5001 963239100770S IC,LOGIC TC4051BF SINGLE 8CH J040405101110S
IC5002 963239003470S IC NJM2586AM J171258600010S
CAPACITORS GROUP
C5000 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C5001 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5002,5003 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C5004 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5006,5007 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C5011 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C5012 nsp C,CERAMIC 68PF-J/50V D010680167160S
C5013,5014 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C5015,5016 nsp C,CERAMIC 68PF-J/50V D010680167160S
C5017,5018 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C5019,5020 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C5021 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C5022 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C5048 nsp C,FILM 0.1UF-J/50V D020104167050S
C5051 nsp C,FILM 0.1UF-J/50V D020104167050S
OTHERS PARTS GROUP
BKT5000,5001 nsp BRACKET 0.8t/SCREW 4010210196100S
CN4001 nsp CN,WAFER C125Z2-13 L109012521320S
CN4002 nsp CN,WAFER C125Z2-15 L109012521520S
CN5000,5001 nsp CN,WAFER C125Z2-13 L109012521320S
CN5002 nsp CN,WAFER C125Z2-15 L109012521520S
CP3401 nsp CN,WAFER C125Z1-13 13P L109012511320S
CP3402 nsp CN,WAFER C125Z1-09 9P L109012510920S
CP3404 nsp CN,WAFER C125Z1-07 7P L109012510720S
CP5000,5001 nsp CN,WAFER C125Z1-13 13P L109012511320S
CP5003 nsp CN.WAFER 2.5MM 8P L102526808010S
z
F5001 963652010500S FUSE T1.6A/250V N751501601160S
F5001A nsp HOLDER,FUSE CLIP G645000050010S
F5001B nsp HOLDER,FUSE CLIP G645000050010S
z
F5002 963652010500S FUSE T1.6A/250V N751501601160S
F5002A nsp HOLDER,FUSE CLIP G645000050010S
F5002B nsp HOLDER,FUSE CLIP G645000050010S
z
F5003 963652010500S FUSE T1.6A/250V N751501601160S
F5003A nsp HOLDER,FUSE CLIP G645000050010S
F5003B nsp HOLDER,FUSE CLIP G645000050010S
z
F5004 963652010500S FUSE T1.6A/250V N751501601160S
F5004A nsp HOLDER,FUSE CLIP G645000050010S
F5004B nsp HOLDER,FUSE CLIP G645000050010S
JACK5000 963643101620D TER,RCA 3PIN RCA-303B1-01 G606303B1010YS

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
