Denon AVR-2113 Service Manual

204
INPUT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC4200 963239000650S IC R2A15218FP J084152180010S
Q4200,4201 943214500030S TR 2SC INC2001AC1 2113CIE3 J522020011210S
Q4204-4206 943215500020S TR 2SA RT1P141C 2113CIE3 J520101411210S
Q4207 943215500020S TR 2SA RT1P141C J520101411210S
Q4208 943216500020S TR 2SC RT1N141C J522101411210S
Q4209-4213 943215500020S TR 2SA RT1P141C J520101411210S
D4210-4212 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
ZD4200 963202500290D D,ZENER ZJ3.6B-0.5W K06003R644522S
RESISTORS GROUP
R4200,4201 nsp 220-J,1/16W-1608 2113CIE3 C20002216M160S
R4202,4203 nsp 100K-J,1/16W-1608 2113CIE3 C20001046M160S
R4212,4213 nsp 100K-J,1/16W-1608 2113CIE3 C20001046M160S
R4222 nsp 470-J,1/16W-1608 2113CIE3 C20004716M160S
R4225 nsp 470-J,1/16W-1608 2113CIE3 C20004716M160S
R4238,4239 nsp 470-J,1/16W-1608 2113CIE3 C20004716M160S
R4223,4224 nsp 10K-J,1/16W-1608 2113CIE3 C20001036M160S
R4258 nsp 10K-J,1/16W-1608 2113CIE3 C20001036M160S
R4240 nsp 470K-J,1/16W-1608 2113CIE3 C20004746M160S
R4241 nsp 1K-J,1/16W-1608 2113CIE3 C20001026M160S
R4242,4243 nsp 470K-J,1/16W-1608 2113CIE3 C20004746M160S
CAPACITORS GROUP
C4200,4201 nsp C,CERAMIC 330PF-J/50V 2113CIE3 D010331167160S
C4202,4203 00D9630224503 C,ELECT 22UF-M/50V 2113CIE3 D040220087060S
C4221,4222 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) 2113CIE3 D040R10087080S
C4204-4211 nsp C,CERAMIC 330PF-J/50V D010331167160S
C4223-4228 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4229,4230 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C4229,4230 963134501890S C,ELECT GE 85C 220UF-M/16V 2113E2 D040221083090S
C4231 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C4231 00D2544569924 C,ELECT GE 85C 100UF-M/25V(RA3) 2113E2 D040101084210S
C4232-4236 nsp C,ELECT 47UF-M/16V D040470083080S
C4237-4239 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4237-4239 00D2544574919 C,ELECT 47UF-M/50V (Pb Free) 2113E2 D040470087070S
C4240-4244 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4245,4246 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C4245,4246 963134501890S C,ELECT GE 85C 220UF-M/16V 2113E2 D040221083090S
C4247 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4248-4252 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
OTHERS PARTS GROUP
CN401 nsp CN,WIRE 2MM 200MM L002201130010S
CN4003 nsp CN,WAFER 11P L109012521110S

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
