Denon AVR-2310 User Manual

2
Getting Started
Connections Playback Remote Control Information Troubleshooting
Specifi cations
ENGLISH
Multi-Zone
Setting items
Setting contents
Amp Assign
Sets the signal output to the
speaker connected to the
SURR. BACK/AMP ASSIGN
terminals.
Normal :The surround back channel audio signals are output.
ZONE2 :The ZONE2 audio signals are output.
Front A Bi-Amp : The bi-amp audio signals are output. Set this for bi-amp
playback of the front A speakers.
Front B Bi-Amp : The bi-amp audio signals are output. Set this for bi-amp
playback of the front B speakers.
Front Height : The front height channel audio signals are output.
Speaker Confi g.
Select speaker confi guration
and size.
(bass reproduction capability)
NOTE
Select “Large” or “Small” not
according to the physical size
of the speaker but according
to the low frequency
reproduction capabilities
based on the frequency set
at “Crossover Frequency”
(vpage 29).
Front : Set the front speaker size.
Large : Use of a large speaker that can adequately play back low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
If “Subwoofer” is set to “No”, “Front” is automatically set to “Large”.
•
•
Center : Set the presence and size of the center speaker.
Large : Use of a large speaker that can adequately play back low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when a center speaker is not connected.
• “Large” is not displayed when “Front” is set to “Small”.
• Even if “Center” has been set to “Large”, when “Front” is set to
“Small”, the “Center” setting automatically switches to “Small”.
•
•
•
Subwoofer : Set the presence of a subwoofer.
Yes : Use a subwoofer.
No : Select when a subwooofer is not connected.
When “Front” is set to “Small”, “Subwoofer” can automatically set
to “Yes”.
•
•
Use this procedure to set the speakers manually or if you wish to change the settings made with
“Audyssey Auto Setup”.
Making the speaker settings (Speaker Setup)
Default settings are underlined.
See overleaf
Use this procedure to change “Audyssey™ Auto Setup” settings or to change the various audio,
video and display settings.
The set can be used without changing these settings. Make these settings as necessary.
For a description of “Menu Map” and operating instructions, see page 20.
Items that can be set with the Manual Setup proceduren

 Making the speaker settings (Speaker Setup) vpage 27

Making the HDMI settings (HDMI Setup) vpage 30

Making the audio settings (Audio Setup) vpage 30

 Making other settings (Option Setup) vpage 32

 Making the ZONE2 settings (ZONE2 Setup) vpage 31
n Examples of Menu Screen Displays
Speaker Setup HDMI Setup Audio Setup
M A N U A L S E T U P
S P E A K E R S E T U P
A m p A s s i g n
S p e a k e r C o n f i g .
B a s s S e t t i n g
D i s t a c e
C h a n n e l L e v e l
C r o s s o v e r F r e q u e n c y
F r o n t S p e a k e r S e t u p
A s s i g n s u r r o u n d b a c k A M P f o r o t h e r u s e
M A N U A L S E T U P
H D M I S E T U P
lamroNegnaRBGR
A u t o L i p S y n c O N
PMAtuOoiduA
FFOlortnoCIMDH
R E T U R N R e t u r n
U s e v i d e o r a n g e f r o m 1 6 ( b l a c k ) t o 2 3 5 ( w h i t e )
M A N U A L S E T U P
A U D I O S E T U P
E X T . I N S W L e v e l
2 c h D i r e c t / S t e r e o
A u t o S u r r o u n d M o d e
E Q C u s t o m i z e
S e t s u b w o o f e r p l a y b a c k l e v e l i n E X T . I N m o d e
ZONE2 Setup Option Setup
M A N U A L S E T U P
Z O N E 2 S E T U P
Bd0hcLleveL
Bd0hcRleveL
V o l u m e D i s p l a y R e l a t i v e
FFOtimiLemuloV
P o w e r O n L e v e l L a s t
lluFleveLetuM
R E T U R N R e t u r n
A d j u s t t h e l e f t c h a n n e l o u t p u t l e v e l
M A N U A L S E T U P
O P T I O N S E T U P
V o l u m e C o n t r o l
S o u r c e D e l e t e
O n - S c r e e n D i s p l a y
Q u i c k S e l e c t N a m e
Z o n e R e n a m e
T r i g g e r O u t
R e m o t e I D S e t u p
2 3 2 C P o r t
M a k e s e t t i n g s f o r v o l u m e c o n t r o l
: Moves the cursor (Up/Down/Left/Right) : Decision the setting : Return to previous menu
Remote control
operation buttons
:
Displaying the menu
Cancel the menu
Settings
Making detailed settings (Manual Setup)

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
