Denon AVR-2313 User Manual

100
Checking the settings
YES
YES
YES
Are the AVR-2313's network settings correct?
Are the router, hub and other peripherals properly connected?
Are the router's settings correct?
Set the IP address and other parameters
properly. For a xed IP setting, check
whether the IP address is redundant with
that of other devices and the subnet mask
setting is correct.
Connect them properly to peripherals.
Check the router's operating instructions
and set it properly.
Check whether there are connection
restrictions due to the MAC address, etc.
NO
NO
NO
5. Network/USB
5.1. Cannot connect to network
YES
Is the LAN cable properly connected?
Turn off the power and check the LAN cable
properly, and then turn the power back on.
NO
Checking the environment
The U2802 and surrounding circuitry are defective.
Checking the set (AVR-2313)
YES
YES
YES
YES
Is output voltage (3.3V) supplied from U3601?
Is output voltage (1.2V) supplied from U3604?
Is the version of IMG or Ethernet SBL displayed in Version check
mode?
Is a voltage (5V) supplied between the pins 2 and 4 of N3601?
The U3601 and surrounding circuitry or
circuitry of 3.3V device are defective.
The U3604 or U2602 and surrounding
circuitry are defective.
The rmware of ethernet is defective.
The circuit from AC inlet to N3601 is defective.
NO
NO
NO
NO

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
