SURROUND MODES AND PARAMETERS
1
Surround
This unit is equipped with a digital signal processing circuit that lets you play program sources in the sound mode to achieve the same sense of presence as in a movie theater. Sound modes and surround parameters This table shows the speakers that can be used in each sound mode and the surround parameters adjustable in each sound mode.
Symbols in the table
S This indicates the audio output channels or surround parameters that can be set. D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.”.
Sound Mode
Channel output Surround Parameter
z1 During playback in PURE DIRECT mode, the surround parameters are
the same as in DIRECT mode.
z2 This item cannot be selected during DSD (SA-CD) signal playback. z3 This item can be selected when a Dolby TrueHD signal is played. z4 Only when “Subwoofer Mode” is set to “LFE+Main”, sound is output
from the subwoofer.
z5 A signal for each channel contained in an input signal is output as
audio.
z6 Audio is output from the front height speaker when the set sound
mode name contains “+PLgz”. For information on how to check the sound mode, see.
z7 This setting is unavailable when the set sound mode name contains
“+PLgx Music”. For information on how to check the sound mode, see.
z8 This setting is possible when the sound mode is “PLgx Cinema” or
“DTS NEO:6 Cinema”.
z9 This setting is possible when the sound mode is “PLg Cinema” or
“Pro Logic”.
z10 Audio is output from the front height speaker when “Assign Mode”
in the menu is set to ”Front Height” and “Audyssey DSX
®
” is set to
“On”.
z11 Audio is output from the front wide speaker when “Assign Mode”
in the menu is set to ”Front Wide” and “Audyssey DSX
®
” is set to
“On”.
z12 Audio is output from the surround back speaker when “Assign Mode”
in the menu is set to ”Surround Back”.
z13 Audio is output from the front height speaker when “Assign Mode” in
the menu is set to ”Front Height”.
z14 Audio is output from the front wide speaker when “Assign Mode” in
the menu is set to ”Front Wide”.
Front
L/R
Center
Surround
L/R
Surround back
L/R
Front height
L/R
Front wide
L/R
Subwoofer
Cinema EQ
z2
Loudness
Management
z3
DIRECT/PURE DIRECT (2 channel)
z1
S D
z4
S
DIRECT/PURE DIRECT (Multi-channel)
z1
S D D D
z5
D
z5
D
z5
D S
DSD DIRECT (2 channel)
z1
S D
z4
S
DSD DIRECT (Multi-channel)
z1
S D D D
z5
D
z5
D
z5
D S
STEREO
S D S
MULTI CH IN
S D D D D
z6
D S
z7
DOLBY PRO LOGIC gz S D D D D S S DOLBY PRO LOGIC gx S D D D D S
z8
S
DOLBY PRO LOGIC g S D D D S
z9
S
DOLBY PRO LOGIC
S D D D S
z9
S
DOLBY PRO LOGIC g A-DSX S D D D
z10
D
z11
D S
z9
S
DOLBY PRO LOGIC A-DSX
S D D D
z10
D
z11
D S
z9
S
DTS NEO:6
S D D D D S
z8
S
DTS NEO:6 A-DSX
S D D D
z10
D
z11
D S
z8
S
Audyssey DSX
®
S D D D
z10
D
z11
D S S
DOLBY DIGITAL
S D D D D
z6
D S
z7
DOLBY DIGITAL Plus
S D D D D
z6
D S
z7
DOLBY TrueHD
S D D D D
z6
D S
z7
S
DTS SURROUND
S D D D D
z6
D S
z7
DTS 96/24
S D D D D
z6
D S
z7
DTS-HD
S D D D D
z6
D S
z7
DTS Express
S D D D D
z6
D S
z7
MULTI CH STEREO
S D D D
z12
D
z13
D
z14
D S
ROCK ARENA
S D D D
z12
D
z13
D
z14
D S
JAZZ CLUB
S D D D
z12
D
z13
D
z14
D S
MONO MOVIE
S D D D
z12
D
z13
D
z14
D S
VIDEO GAME
S D D D
z12
D
z13
D
z14
D S
MATRIX
S D D D
z12
D
z13
D
z14
D S
VIRTUAL
S D S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
