Denon AVR-2313 User Manual

161
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
PCB ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the PCB ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model
BK : Black model SP : Premium Silver model NOT FIXED : Update will be next version
Ref. No. Part No. Part Name Remarks Q'ty New
P8 nsp 7CH_AMP PCB ASSY E3 7025HK1113010 1 *
P8 nsp 7CH_AMP PCB ASSY E2 7025HK1113020 1 *
P8 nsp 7CH_AMP PCB ASSY E1C 7025HK1113030 1 *
P18A nsp SPK PCB ASSY E3 7025HK1113011 1 *
P18A nsp SPK PCB ASSY E2 7025HK1113021 1 *
P18A nsp SPK PCB ASSY E1C 7025HK1113031 1 *
P18 - PCB SMPS -
P19 - PCB SPK -
P12A nsp REG_CNT PCB ASSY E3 7025HK1113012 1 *
P12A nsp REG_CNT PCB ASSY E2 7025HK1113022 1 *
P12A nsp REG_CNT PCB ASSY E1C 7025HK1113032 1 *
P11 - PCB REG -
P12 - PCB REG_CNT -
P14 - PCB SIDE _CNT -
P15 - PCB RS232 -
P17 - PCB RC5_MXPORT -
P20 - PCB FRONT_CNT -
P3A nsp FRONT PCB ASSY E3 7025HK1113013 1
P3A nsp FRONT PCB ASSY E2 7025HK1113023 1
P3A nsp FRONT PCB ASSY E1C 7025HK1113033 1
P2 - PCB USB -
P3 - FRONT PCB ASSY -
P4 - PCB FUNCTION -
P5 - PCB CNT -
P6 - PCB FRONT HDMI_GUIDE -
P7 - PCB GUIDE_R -
P9 - PCB TOP_GUIDE -
P10 - PCB GUIDE_L -
P13 nsp AUDIO PCB ASSY E3 7025HK1113014 1 *
P13 nsp AUDIO PCB ASSY E2 7025HK1113024 1 *
P13 nsp AUDIO PCB ASSY E1C 7025HK1113034 1 *
P21A nsp VPT PCB ASSY E3 7025HK1113015 1 *
P21A nsp VPT PCB ASSY E2 7025HK1113025 1 *
P21A nsp VPT PCB ASSY E1C 7025HK1113035 1 *
P21 - PCB PREOUT -
P22 - PCB VIDEO -

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
