PARTS LIST OF PCB UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model
7CH_AMP PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q401,402 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q403 00D2710318909 TR 2SA 2N5401S J520254010010S
Q405 00D2710318909 TR 2SA 2N5401S J520254010010S
Q406 00D2730479909 TR 2SC 2N5551S J522255510010S
Q407,408 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q411,412 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q413,414 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q415 00D2710318909 TR 2SA 2N5401S J520254010010S
Q418 00D2730479909 TR 2SC 2N5551S J522255510010S
Q419,420 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q423,424 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q425,426 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q427 00D2710318909 TR 2SA 2N5401S J520254010010S
Q430 00D2730479909 TR 2SC 2N5551S J522255510010S
Q431,432 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q435,436 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q437,438 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q439 00D2710318909 TR 2SA 2N5401S J520254010010S
Q442 00D2730479909 TR 2SC 2N5551S J522255510010S
Q443,444 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q447,448 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q449,450 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q451 00D2710318909 TR 2SA 2N5401S J520254010010S
Q454 00D2730479909 TR 2SC 2N5551S J522255510010S
Q455,456 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q459,460 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q461,462 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q463 00D2710318909 TR 2SA 2N5401S J520254010010S
Q466 00D2730479909 TR 2SC 2N5551S J522255510010S
Q467,468 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q471,472 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q473,474 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q475 00D2710318909 TR 2SA 2N5401S J520254010010S
Q478 00D2730479909 TR 2SC 2N5551S J522255510010S
Q479,480 00D9600196205 TR 2SA KSA992F J5000992F0050S
Q483,484 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
D401-442 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D457,458 963201500170D
D,SWITCHING CHIP
LBAS16HT1G FAST
K005041480230S
ZD401 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD402,403 963202500410S D,ZENER ZJ4.7B-0.5W K06004R744522S
ZD404 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
ZD405,406 963202500410S D,ZENER ZJ4.7B-0.5W K06004R744522S
ZD407 963202500300D D,ZENER ZJ5.1A-0.5W K06005R134522S
