Denon AVR-2313 User Manual

210
REG_CNT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC4600 00D2630553006 IC NJM7805FA J126780500130S
IC4601 00D2630554005 IC NJM7905FA J126790500020S
IC4602 00D2630553006 IC NJM7805FA J126780500130S
IC4603 00D2630810008 IC NJM7808FA J126780800030S
IC4604 00D2630503001 IC NJM7908FA J126790800020S
IC4605 00D2630553006 IC NJM7805FA J126780500130S
IC4700 00D2631286903 IC PQ120DNA1ZPH 12V 1A J126120010010S
IC4701 236810090504S IC ILX3232D J046323200020S
D4600 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D4601,4602 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D4603,4604 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D4605-4607 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D4608,4609 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4610 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D4611-4614 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4615 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D4616-4631 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4703 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST K005041480230S
ZD4600,4601 963202500360D D,ZENER ZJ33B-0.5W/5MA-52MM K06033R044522S
ZD4700 963202500400S D,ZENER,ZJ16B-0.5W/5MA-52MM K06016R044522S
CAPACITORS GROUP
C4600 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4601 963134011290S C,ELECT 4700UF-M/16V D040472083020S
C4602 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C4603 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4604 00D9630333203 C,ELECT 100UF-M/16V E3 D040101083090S
C4604 963134001860S C,ELECT 470UF-M/16V E2,E1C D040471083080S
C4605 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4606 00D9630333203 C,ELECT 100UF-M/16V E3 D040101083090S
C4606 963134001860S C,ELECT 470UF-M/16V E2,E1C D040471083080S
C4607 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S
C4608 00D9630333203 C,ELECT 100UF-M/16V E3 D040101083090S
C4608 963134001860S C,ELECT 470UF-M/16V E2,E1C D040471083080S
C4609 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S
C4610 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C4611 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4613 nsp C,FILM 0.1UF-J/50V D020104167050S
C4614 963134010700S C,ELECT 2200UF-M/25V D040222084030S
C4615,4616 nsp C,FILM 0.1UF-J/50V D020104167050S
C4618 nsp C,FILM 0.1UF-J/50V D020104167050S
C4702,4703 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4704-4706 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4707 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4711,4712 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4716,4717 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4718,4719 nsp C,CERAMIC 33PF-J/50V D010330167160S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
