Denon AVR-2313 User Manual

220
HDMI PCB UNIT ASS'Y
NOTE
: When replacing the U3002 or U1602, use the U3002(963243101030D) or U1602(963248100710S).
When the following are replaced, always rewrite with updated rmware using DFW.
(Refer to "PROCEDURE FOR UPGRADING THE VERSION OF THE FIRMWARE" (58 page).)
• HDMI PCB UNIT ASS'Y
• U1602 (MX25L6406EM2I-12G)
• U2206 (EPM240T100C5N)
• U3002 (R5F56108VNFP)
• U2003 (MX29LV160DBTI-70G)
d
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
U1001 236810057606S IC LOGIC ADV3002BSTZ J040300205510S
U1201 nsp IC,LOGIC AD8195 J040819505510S
U1301 943239100760S IC,LOGIC TC74VHC4051AFT TOSHIBA J040744051360S
U1302 963236101220D IC,LOGIC ADV7850 HDMI 1.4A J040785005510S *
U1303 00D2623436907 IC,LOGIC TC74VHC244FT J040742445530S
U1601 963236101310S
IC,LOGIC-ENCODER,I9ADV8003-2
BGA425 ADV8003KBCZ-3C DUAL HDMI TX
J045800302010S *
U1602 963248100710S
IC MEMORY FLASH
(MX25L6406EM2I-12G)
J005256401210S
U1801,1802 nsp IC,MEMORY-RAM K4T51163QJ-BCE7 J001451163370S *
U2001 nsp
IC,ANALOG,I9ADSP21487KSWZ-4B3016
SHARC PROCESSOR LQFP176
J080214875560S
U2002 943246012690S IC MEMORY-RAM(W9864G6JH-6) J001986466010S
U2003 963248101700S MX29LV160DBTI-70G 8952400000240 *
d
U2201,2202 00D9630237503 MODULE JSR1165-C E100116500040S
U2204 00D2623077900 IC TC74VHCU04FT J040740405580S
U2205 236810062608S IC LC89058W-E J046890580020S
U2206 963243101020S IC,PAL/PLD,I9EPM240T100C5N TQFP100 8952231300040 *
U2207 963239002150S IC SN74LVC244APWR J040742440230S
U2401 943239100690S IC,LOGIC-D/A CONVER PCM5100 J042510005510S
U2402 231310009508S IC PQ033DNA1ZPH J126033010010S
U2403 236810086505S IC AK5358BET-E2 J043535805520S
U2404 236810073509S IC AK4358VQ-L J042435800010S
U2406-2409 00D2631289900 IC AZ4580M J121458000020S
U2602 23681011260AS IC,ANALOG DM860A NETWORKED J080860A05510S
U2603 nsp IC MEMORY FLASH (H27U1G8F2BTR) J005270820020S
U2604,2605 963246100740D IC, MEMORY-RAM A3V56S30FTP-G6 J001030563060S
U2802 nsp IC,LINEAR-DRIVER LAN8720A J127872005510S
U2803 00D2623711004 IC LOGIC SAA7121H J045712100010S
U2805 nsp IC,LOGIC-DECODER MFI337S3959 J044337395910S
U2806 nsp IC,LINEAR-DRIVER NCP380HMU J127380150010S
U3002 963243101030D
IC CPU MICRO PROCESS
(R5F56108VNFP)
8952231300010 *
U3003 943239100720S
IC,MEMORY-EEPROM
R1EX24256BSAS0A
J000242565570S
U3601-3605 nsp IC EX3AV J048030030010S
U3607 231310009508S IC PQ033DNA1ZPH J126033010010S
U3608 943239100730S IC,LINEAR-RESET PST8448UR J125844800010S
Q1001-1004 943216500020S TR 2SC RT1N141C J522101411210S
Q1005-1008 943216500050S TR 2SC RT1N441C J522104411210S
Q1303-1305 943216500020S TR 2SC RT1N141C J522101411210S
Q1606 963223500020D SEMI,FET CHIP UPA672T-T1-A SC-70 J543672001010S
Q1801 943214500020S TR 2SC 2SC3052 J522305200050S
Q2201,2202 943216500020S TR 2SC RT1N141C J522101411210S
Q3001 943214500020S TR 2SC 2SC3052 J522305200050S
Q3002 943215500030S TR 2SA RT1P441C J520104411210S
Q3201 943214500020S TR 2SC 2SC3052 J522305200050S
Q3202 963219002180S TR 2SD2114KT146W J5232114K0010S
NOTE
:
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
