Denon AVR-2313 User Manual

206
SPK_SMPS PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
z
IC4140 231010091708S IC,LINEAR POWER TOP258MG SDIP10 J122258001010S
z
IC4142 00D2623047008 IC PC123X2YFZ (DIP4P SHARP) K614123000010S
IC4143 212050010508S IC KIA2431AP J126243118010S
Q4000-4004 943215500020S TR 2SA RT1P141C J520101411210S
Q4006-4010 943216500020S TR 2SC RT1N141C J522101411210S
D4000-4004 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST K005041480230S
D4006 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D4007 963203500300D D,RECTIFIER BRIDGE DIODE K047100600220S
D4140-4148 963201500160D D,SWITCHING 1N4007 52REEL K000400700220S
D4149 963204500210D D,SCHOTTKY S30SC6MT 60V 30A K120300600010S
D4150 00D2760401905 D,SWITCHING 1SS133T K000013300520S
ZD4147-4149 963202500370D D,ZENER ZJ39B-0.5W/5MA-52MM E3 K06039R044522S
ZD4150-4157 963202500350D D,ZENER ZJ22B-0.5W K06022R044522S
ZD4158 963202500370D D,ZENER ZJ39B-0.5W/5MA-52MM K06039R044522S
ZD4159 963202500320D D,ZENER ZJ5.6B-0.5W/5MA-52MM K06005R644522S
ZD4160 00D9600095704 ZENER DIODE MTZJ6.2B-0.5W E3 K06006R244520S
ZD4160 00D2760665903 ZENER DIODE MTZJ16B-0.5W E2,E1C K06016R044520S
TR4140 963222500150D SEMI,FET CHIP KMB2D0N60SA J543206005510S
TR4142 963213500170D SEMI,TR/GE NPN 2SC KTC3198G J5023198G0000S
RESISTORS GROUP
R4000,4001 963125010110S R,METAL FILM 470-J,2W C060047166060S
R4002 nsp R,METAL FILM 10-J,1W E3 C060010065050S
R4002 nsp R,METAL FILM 10-J,Axial E2,E1C C00001006P520S
R4003 963125010100S R,METAL FILM 10-J 2W C060010066050S
R4004 nsp R,METAL FILM 10-J,1W E3 C060010065050S
R4004 nsp R,METAL FILM 10-J,Axial E2,E1C C00001006P520S
R4005 963125010100S R,METAL FILM 10-J 2W C060010066050S
R4006 nsp R,METAL FILM 10-J,1W E3 C060010065050S
R4006 nsp R,METAL FILM 10-J,Axial E2,E1C C00001006P520S
R4007 963125010100S R,METAL FILM 10-J 2W C060010066050S
R4008 nsp R,METAL FILM 10-J,1W E3 C060010065050S
R4008 nsp R,METAL FILM 10-J,Axial E2,E1C C00001006P520S
R4009 963125010100S R,METAL FILM 10-J 2W C060010066050S
R4010 nsp R,METAL FILM 10-J,1W E3 C060010065050S
R4010 nsp R,METAL FILM 10-J,Axial E2,E1C C00001006P520S
R4011 963125010100S R,METAL FILM 10-J 2W C060010066050S
R4012 nsp R,METAL FILM 10-J,1W E3 C060010065050S
R4012 nsp R,METAL FILM 10-J,Axial E2,E1C C00001006P520S
R4013 963125010100S R,METAL FILM 10-J 2W C060010066050S
R4014 nsp R,METAL FILM 10-J,1W E3 C060010065050S
R4014 nsp R,METAL FILM 10-J,Axial E2,E1C C00001006P520S
R4015 963125010100S R,METAL FILM 10-J 2W C060010066050S
R4025-4027 963125500070D R,METAL FILM 100PPM 1.1K-J C060011265050S
R4028 nsp R,METAL FILM 10K-J,1/4W C060103063050S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
