Denon AVR-2313 User Manual

163
Ref. No. Part No. Part Name Remarks Q'ty New
37 963403100480S CABINET TOP SP 3007211916010S 1
38 544510081006M LABEL HOT-SURFACE E3 5507000003730S 1
39 nsp CUSHION,FRONT FFC 4050214335000S 1 *
40 943419100250D COVER SAFETY BLACK BKE2 4310215731000S 2
40 943419100260D COVER SAFETY CLEAR SPE1C 4310215731100S 2
41 45451000500AM HOLDER COVER BKE2 4310215741000S 8
41 45451000501AM HOLDER COVER SPE1C 4310215741100S 8
★
42 nsp CLAMP CABLE 4330040343010S 5
★
43 963219003340S
TR 2SC KTC3964/TO126S-BULK
(MAIN HEAT SINK TR-2)
Q409,Q421,Q433,Q445
,Q457,Q469,Q481
J502396400010S 1
★
44 00D9630235301 TR 2SD2560Y
Q404,Q416,Q428,Q440
,Q452,Q464,Q476
J5032560Y0170S 1
★
45 00D9630235204 TR 2SB1647Y
Q410,Q422,Q434,Q446
,Q458,Q470,Q482
J5011647Y0170S 1
SCREWS
A nsp
SCREW
+2S 3X8 B-TYPE(DA CHENG) ZNW/BH
B020030081B10S 29
C nsp SCREW (+2S 3*8(ROUND BK/BH) B020230083B10S 46
D nsp SCREW+2+S 3X6(ROUND)BK/BH B020230063B10S 6
G nsp
SCREW(+3S 4*10 P+S-WASHER(ROUND)
BK/BH)
B028940101B11S 4
I nsp SCREW (+2S 3*17 B-TYPE ZNW/BH) B020030171B10S 3
J nsp SCREW (+2S 4*8 B-TYPE(DOT) BK/BH) E3,E2 1500040083B10S 8
J nsp SCREW (+2S 4*8 B-TYPE(DOT) BK/BH) SP 1500040083B10S 2
J nsp SCREW (+2S 4*8 B-TYPE(DOT) NI/BH) SP 1500040084B10S 6
K nsp
SCREW+2S 3X10 B-TYPE(DOT)(DA
CHENG) BK/BH
E3 B020030103B11D 31
K nsp
SCREW+2S 3X10 B-TYPE(DOT)(DA
CHENG) BK/BH
E2,E1C B020030103B11D 33
L nsp SCREW (+3S 3*6 DOT BK/BH) B020930063B10S 12
H nsp
SCREW+2S 3X14 P(Φ6)+S-WASHER ZNY/
HH
B018230141H11D 21
SCREWS
★
101 963606501580S CABLE,FLAT CARD 1.0MM 40P N711402412490S 1 *
★
102 963606501590S CABLE,FLAT CARD 1.0MM 23P N711232912490S 1 *
s
s
s
s

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
