Denon AVR-X1200W Service Manual

SCHEMATIC DIAGRAMS (06/17)
SCH06_MCU LEVEL CHG
STBY POWER GND LINE POWER- LINE POWER+ LINE ANALOG AUDIO DIGITAL AUDIO TMDS SIGNAL ANALOG VIDEO
MCU_LEVEL_CHG PART
OE1
OE2
1.3.3V
3.RX
2.TX
4.DGND
UPDATE
1.00mm 4PIN FFC
PROTECT PARTS
DC_DET/ASO
DETECT PARTS
MIC/ H/P
6.FRONT_RLY
7.C/S_RLY
3.H/P_RLY
5.ASO_DET 7.DC_PROT 1.THERMALDET_A
8.THERMALDET_B
3.-12V 4.MUTE_+B
6.DGND 2.RLY_GND 5.+12V
8.SB_RLY
4.HI-B_RLY
1.CURRENT_DET
9.AMPSIG_DET 2.CURRENT_GND
B_DETECT
C7604
0.01uF
R7626
120K
R7625
100
C7605
0.01uF
R7629
120K
R7628
100
C7603
0.01uF
R7624
100
1 2 3 4 5 6 7 8 9 10
1112151617181920 14 13
IC761
SN74LVC244APWR
C7602
OPEN
C7601
0.1uF
R7601
33
R7602
33
R7603
33
R7608
4K7
R7605
10
0
R7604
100
R7606
100
R7607
100
Q7601
CVTRT1N141C
Q7606
CVT2SC3052
Q7607
CVT2SC3052
Q7605
CVT2SC3052
R7609
33
3
4 2
1
CN763
CJP04GB113ZY
R7618
10K
R7610
4K7
R7612
4K7
R7611
3K9
R7617
10K
Q7602
CVTRT1N141C
Q7603
CVTRT1N141C
Q7604
CVTRT1N141C
R7623
3K9
R7627
22K
R7630
22K
L7601
CB03YTYH600
L7602
CB03YTYH600
L7603
CB03YTYH600
L7604
CB03YTYH600
L7605 CB03YTYH600 L7606 CB03YTYH600
L7607
CB03YTYH600
L7608
CB03YTYH600
L7609
CB03YTYH600
L7610
CB03YTYH600
L7611
CB03YTYH600
L7612
CB03YTYH600
L7613
CB03YTYH600
L7614
CB03YTYH600
L7615
CB03YTYH600
L7616
CB03YTYH600
L7617
CB03YTYH600
1 2 3 4 5 6 7 8
CN762
CJP08GI288ZY
L7618
CB03YTYH600
987654321
CN761
CJP09GI288ZY
T7601
R7613 3K3
R7619 3K3
SWM3.3V
H/P_RLY
FRONT_RLY
C/S_RLY
PLD_WRITE
JTAG_TDO
JTAG_TMS/APLD_CS
JTAG_TDI/APLD_DATA
JTAG_TCK/APLD_CLK
AP_CS
AP_DA
AP_CK
JTAG_TDOO
JTAG_TMS
JTAG_TDI
JTAG_TCK
DGND
TXD RXD
DC_DET/ASO
H/P_DET/MIC_DET
H/P_DET
MIC_DET
THERMAL_A
THERMAL_B
MUTE_+B
RLY_GND
+12V
-12V
DGND
HI-B_RLY
SB_RLY
CURRENT_DET
AMPSIG_DET
B_DETECT
7B
TO B7
4C
TO C4
C5
TO 5C
C6
TO 6C
CN761
TO BN501
CN762
TO BN502
108
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
A
B
C
D
E
F
G
H
J
K
L
M
A
B
C
D
E
F
G
H
J
K
L
M
1
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
