3. Selecting the Mode for Service-related Operations
3.1. Actions
Select diagnostic mode (service path check mode), protection history display mode.
3.2. Starting up
AVR-X1200W
2. While holding down buttons "
ZONE2 SOURCE
", "
DIMMER
" and "
STATUS
" simultaneously, press the power button
to turn on the power.
AVR-S710W
2. While holding down buttons "
TUNER PRESET CH+
", "
TUNE -
" and "
TUNE +
" simultaneously, press the power but-
ton to turn on the power.
Select the desired mode using the "
TUNER PRESET CH+
" button, then press the "
STATUS
" button to conrm.
3.3. Displaying and Selecting Each Mode
The information shown on the display switches each time the "
TUNER PRESET CH+
" button is pressed.
Press the "
STATUS
" button to set the currently displayed mode and restart the device.
q
FLD
1 . S E R V I C E C H E C K
Service Path Check Mode：
The Video and Audio paths can be checked.
This function is convenient for conrming problem paths in the product and checking the paths
after repairing.
w
FLD
2 . P R O T E C T I O N
The protection history can be checked.
e
FLD
4 . O P I N F O
Operation Info for the unit can be checked.
r
FLD
5 . T U N E R F R Q S E T
Enables reception STEP of the ANALOG TUNER to be changed.
t
FLD
6 . R E M O T E I D
This function is for operating only the desired AV receiver.
3.3. Canceling the selected mode
Press the power button to turn off the power.
