Denon AVR-X1200W Service Manual

NO
NO
NO
Is IC601(TOP268VG) damaged?
Is D6001 - D6004 damaged?
Repair the short circuited area on the
PCB.
Check the damaged parts.
Replace the damaged part.
Replace the damaged part.
Is the fuse (F6001) functioning prop-
erly?
Are there any short circuits caused by
the soldering on the PCB?
Are any parts damaged?
Replace the IC601(TOP268VG) and
D6001 - D6004.
DC 5V is not output.
YES
YES
YES
YES
YES
YES
6. SMPS
85

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
