Denon AVR-X1200W Service Manual

WIRING DIAGRAM
3P
3P
3P
3P
3P
3P
3P
3P
3P
3P
3P
3P
3P
3P
FRONT PCB
3P
BN131
3P
CN103
3P
PHONE PCB
CN104
STANDBY
PCB
5P
USB & MIC PCB
BN104
BN12B1
MAIN PCB
POWER PCB
DIGITAL PCB
CN751
6P
CN741
6P
BN601
5P
CN823
3P
CN754
3P
BN705
7P
2P
CN602
2P
CN601
7P
CN502
AC CORD
FRONT<->DIGITAL
USB -> DIGITAL
H/P-FRONT
H/P <- MAIN
POWER->DIGITAL
SMPS<-AC IN
FRONT-HDMI PCB
23P
CN811
23P
CN701
BN301
5P
CN302
TRANS -> SMPS
TRANS
TRANS -> FRONT
TRANS->MAIN
TRANS -> REGUL.
5P
5P
MIC-FRONT
HDMI -> DIGITAL
BN12A
BN12B
CN102
BN101_1
BN101
5P
27P
27P
9P
9P
DIFF-AMP PCB
CN201
15P
CN822
REGULATOR
-> DIGITAL
REGULATOR->DIGITAL
ANT1 ANT2
CY920
PCB TO PCB
PCB TO PCB
PCB TO PCB
PCB TO PCB
PCB TO PCB PCB TO PCB PCB TO PCB
PCB TO PCB
PCB TO PCB
7P
7P
7P
7P 7P
7P
7P
REGULATOR PCB
64P
8P
8P
CN762
CN761
9P
9P
5P
CN804
CN821
CN508
9P
9P
BN502
BN501
PCB TO PCB
15P
BN56B
BN57B BN51B
BN52B
BN53B
BN54B
BN55B
BN51A
BN51A
BN51A
BN51A
BN51A
BN51A
BN51A
CN56B
CN57B CN51B
CN52B CN53B
CN54B
CN55B
CN56A
CN57A CN51A CN52A
CN53A
CN54A CN55A
64P
CN802
CN801
3P
BN302
WIRING DIAGRAM
98

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
