FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FRONT PCB
Ref. No. of EXPLODED VIEW : P 1
STANDBY PCB
Ref. No. of EXPLODED VIEW : P 2
PHONE PCB
Ref. No. of EXPLODED VIEW : P 3
USB&MIC PCB
Ref. No. of EXPLODED VIEW : P 4
FRONT-HDMI PCB
Ref. No. of EXPLODED VIEW : P 5
HDMI CABLE GUIDE PCB
Ref. No. of EXPLODED VIEW : P 7
FRONT CABLE GUIDE PCB
Ref. No. of EXPLODED VIEW : P 8
TOP COVER
REGULATOR PCB
See "DISASSEMBLY"
5. REGULATOR PCB
and "EXPLODED VIEW"
REGULATOR PCB
Ref. No. of EXPLODED VIEW : P 11
RADIATOR ASSY
See "DISASSEMBLY"
3. RADIATOR ASSY
and "EXPLODED VIEW"
MAIN PCB
Ref. No. of EXPLODED VIEW : P 6
BIAS TR PCB
Ref. No. of EXPLODED VIEW : P 9
DIFF AMP PCB
Ref. No. of EXPLODED VIEW : P 12
PHONE WIRE GUIDE PCB
Ref. No. of EXPLODED VIEW : P 17
DIGITAL PCB ASSY
See "DISASSEMBLY"
2. DIGITAL PCB ASSY
and "EXPLODED VIEW"
DIGITAL PCB
Ref. No. of EXPLODED VIEW : P 13
CY920, MODULE
Ref. No. of EXPLODED VIEW : P 14
TUNER PCB
Ref. No. of EXPLODED VIEW : P 15
TRANS POWER
See "DISASSEMBLY"
6. TRANS POWER
and "EXPLODED VIEW"
TRANS POWER
Ref. No. of EXPLODED VIEW : P 16
POWER PCB
See "DISASSEMBLY"
4. POWER PCB
and "EXPLODED VIEW"
POWER PCB
Ref. No. of EXPLODED VIEW : P 10
DISASSEMBLY
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "Precautions During Work" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing
the work. Failure to shape the wires correctly may cause problems such as noise.
15
