Denon AVR-X1200W Service Manual

BLOCK DIAGRAM
ANALOG AUDIO BLOCK
AUDIO IN
CEN
FR
FL
+
-
-
+
-
+
+
-
-
+
SL
SR
NJU72340A
VOL IC
SPK OUT
PRE OUT
MAIN
TUNER
AD_FL
AD_FR
TO DIGITAL
AUDIO BLOCK
DA_FL
DA_FR
DA_CEN
DA_SW
DA_SL
DA_SR
CBL/SAT
MIC(AUTO SETUP)
NETWORK
SW1MUTE
AUDYSSEY
MEDIA PLAYER
P-AMP
ZONE2
AVR-X1200W E3 ONLY
MUTE
DA_FL
DA_FR
DA_CEN
DA_SW
DA_SL
DA_SR
DA_SBL
DA_SBR
ANA_FL
ANA_FR
H/P L
GND
H/P R
H/P OUT
+
-
-
+
SBL
SBR
BD3812F
VOL IC
SW2
DA_SBL
DA_SBR
(FL-H/FL-B/BI-AMP-FL/ZONE-FL)
(FR-H/FR-B/BI-AMP-FR/ZONE-FR)
32.768kHz
FM/AM
DA01
DA02
DA03
DA04
DA05
DA06
DA03
DA04
DA05
DA06
DA07
DA08
ANA01
DA07
DA08
DA01
DA02
ANA01
ANA02
94

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
