Denon AVR-X520BT User Manual

Playing files stored on USB memory
devices
1
Connect the USB memory device to the USB port.
(v p. 32)
2
Press USB to switch the input source to “USB”.
.
Folder
Music
USB [1/2]
Option OPTION
3
Use ui p to select the file to be played, then press
ENTER.
Playback starts.
Operation buttons
Function
1/3
Playback / Pause
8 9
Skip to previous track / Skip to next track
(Press and hold) Fast-reverse / Fast-forward
ENTER
Playback / Pause
(Press and hold) Stop
u i
Skip to previous track / Skip to next track
(Press and hold) Fast-reverse / Fast-forward
NOTE
Note that Denon will accept no responsibility whatsoever for any problems arising with the
data on a USB memory device when using this unit in conjunction with the USB memory
device.
o
Operations accessible through the option
menu
0
“Performing repeat playback (Repeat)” (v p. 54)
0
“Performing random playback (Random)” (v
p. 54)
0
“Adjusting the tone (Tone)” (v p. 55)
0
“Displaying your desired video during audio playback (Video
Select)” (v
p. 57)
Contents
Connections Playback Settings Tips Appendix
40
Front panel Display Rear panel Remote Index

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
