Denon AVR-X520BT User Manual

Menu map
When using menu operations, connect this unit to a TV and operate this unit while viewing the TV.
The recommended settings are configured for this unit by default. You can customize this unit based on your existing system and your preferences.
Setting items Detailed items Description Page
.
Audio
Surr.Parameter Adjusts surround sound parameters. 70
Restorer Expands the low and high frequency components of compressed audio content such as
MP3 files to enable richer audio playback.
73
Audio Delay Compensates for incorrect timing between video and audio. 74
Volume Make volume settings. 74
Room EQ Set whether to use the equalizer or not. 75
.
Video
HDMI Audio Out Select HDMI audio output device. 76
HDMI PassThrough Selects how this unit will pass HDMI signals to the HDMI output in standby power mode. 76
Pass Source Sets the HDMI connector that inputs HDMI signals when in standby. 77
Contents Connections Playback Settings Tips Appendix
Settings
66
Front panel Display Rear panel Remote Index

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
