Denon AVR-X520BT User Manual

Front Display
Adjust the display brightness of this unit.
o
Dimmer
Bright
(Default):
Normal display brightness.
Dim: Reduced display brightness.
Dark: Very low display brightness.
Off: Turns the display off.
0
When the display brightness is set to “Off”, the display turns off as in the standby
state.
0
You can also adjust the display by pressing DIMMER on the main unit.
Firmware
When new firmware is supplied, update this unit using the USB port.
Use a USB memory device to update the firmware.
o
Update Start
Start the firmware update.
To update the firmware, connect the USB memory device to the USB
port on this unit.
Setup Lock
Protect settings from inadvertent changes.
o
Lock
On: Turn protection on.
Off
(Default):
Turn protection off.
Perform the following operations to set “Lock” to “Off”.
1. Press and hold SETUP for more than 3 seconds.
“Setup Lock:0On1” appears on the display.
2.
Use o p to select “Off”, then press ENTER.
NOTE
When “Lock” is set to “On”, no setting items are displayed except for “Setup
Lock”.
Contents Connections Playback Settings Tips Appendix
91
Front panel Display Rear panel Remote Index

Denon AVR-X520BT Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	70 W
HDMI in	5
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	-
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Ethernet LAN	No
AM band range	552 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-HD, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7500 g
