Denon S-302 Service Manual

107
S-302
1U-3811A/B/C D.AMP/SMPS P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101-103 00D 263 1277 909 RC4580IDR *
IC201 00D 262 3502 909 TAS5066PAGRG4
IC202 00D 262 3504 907 SN74HCU04APWR
IC203,204 00D 262 3501 900 PCM1803DBR
IC205 00D 263 1100 005 KIA7805API-U/P
IC206 00D 262 3503 911 TAS5142DKD
IC207 00D 262 3503 908 TAS5121DKDR
IC208 00D 262 3082 924 BD4730G-TR
IC401 00D 265 0118 007 STR-F6267S(LF1351) for E2
IC401 00D 265 0116 009 STR-F6238S(LF1351) for E3, JP
IC402 00D 262 3508 903 SPI-8002TW
IC403 00D 263 1100 021 KIA7812API-U/P
IC404 00D 263 1099 022 KIA7912PI-U/P
IC405 00D 263 1155 005 SE-B2(LF12)
IC406 00D 263 1100 063 KIA7809API-U/P
IC407 00D 262 3047 008 PC123Y22
TR101,102 00D 273 0460 905 KTC2875-B-RTK/P
TR103,104 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR105 00D 273 0460 905 KTC2875-B-RTK/P
TR110 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR201 00D 273 0464 901 KTC3875S-GR-RTK/P
TR202,203 00D 271 0312 905 KTA1504S-GR-RTK/P
TR204 00D 273 0464 901 KTC3875S-GR-RTK/P
TR205 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR206 00D 273 0468 907 KTC3199-GR-AT/P
TR207 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR208 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR401 00D 273 0468 907 KTC3199-GR-AT/P
TR402,403 00D 273 0464 901 KTC3875S-GR-RTK/P
TR404 00D 271 0320 900 KTA1517-GR-RTK/P
TR405 00D 274 0160 907 2SD2144STPU
TR406,407 00D 271 0320 900 KTA1517-GR-RTK/P
TR501,502 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
D101 00D 276 0401 905 1SS133T77 (TAPE)
D102-107 00D 276 0773 905 RB501V-40 +2125
D113 00D 276 0401 905 1SS133T77 (TAPE)
D201-206 00D 276 0750 902 RB521S-30TE61 +REF
D207-212 00D 276 0401 905 1SS133T77 (TAPE)
D213,214 00D 276 0717 903 1SS355 TE-17 +C
D215,216 00D 276 0401 905 1SS133T77 (TAPE)
D217 00D 276 0401 905 1SS133T77 (TAPE) for E3, JP
D401,402 00D 276 0401 905 1SS133T77 (TAPE)
D403,404 00D 276 0750 902 RB521S-30TE61 +REF
D405 00D 276 0802 009 GS1B660
D406-410 00D 276 0750 902 RB521S-30TE61 +REF
D411,412 00D 276 0727 919 AL01ZT (WK)
D413 00D 276 0758 001 SARS03
D414 00D 276 0727 919 AL01ZT (WK)
D415,416 00D 276 0772 003 1N4004
D417 00D 276 0401 905 1SS133T77 (TAPE)
D418,419 00D 276 0782 909 RN1Z
D420 00D 276 0832 008 FMX-G22S
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon S-302 Specifications

General

Audio decoders	-
RMS rated power	100 W
Audio output channels	5.1 channels
Audio formats supported	AAC, MP3, WAV, WMA
Signal-to-Noise Ratio (SNR)	92 dB
Satellite speaker frequency range	80 - 90000 Hz
Subwoofer type	Active subwoofer
Wireless subwoofer	No
FM radio	Yes
AM band range	52 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Disc loading type	Tray
Disc types supported	CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW
Playback disc formats	CD audio, CD video, VCD
Number of optical discs	1 discs
Optical disc player type	DVD player
HDMI in	0
USB version	2.0
Audio (L/R) in	3
Composite video in	2
Digital audio coaxial in	1
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	78 W
Product color	Black
Apple docking compatibility	iPod
Video formats supported	DIVX

Weight and Dimensions

Subwoofer weight	11200 g
Subwoofer dimensions (WxDxH)	212 x 406 x 378 mm
Front speaker dimensions (WxDxH)	131 x 76 x 335 mm
