114
S-302
PARTS LIST OF EXPLODED VIEW
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ 本表に"nsp" と記載されている基板 ASS’Y は供給できません。基板 ASS’Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan mode
Ref. No. Part No. Part Name Remarks Q'ty New
1 00D1U-3808A MAIN UNIT for E2 1 *
1 00D1U-3808B MAIN UNIT for E3 1 *
1 00D1U-3808C MAIN UNIT for JP 1 *
2 00D1U-3809A VIDEO UNIT 1*
3 nsp L.PWR/DISP UNIT for E2 1 *
3 nsp L.PWR/DISP UNIT for E3, JP 1 *
3-1 DISPLAY CENTER UNIT 1
3-2 DISPLAY RIGHT UNIT 1
3-3 DISPLAY LEFT UNIT 1
3-4 USB TERM. UNIT 1
3-5 LOCAL POWER UNIT 1
3-6 RS-232C UNIT 1
3-7 SWITCH UNIT 1
3-8 TUNER/R to R/IPOD UNIT 1
3-9 IF-1 UNIT 1
3-10 IF-2 UNIT 1
3-11 IF-3 UNIT 1
3-12 AUX IN UNIT 1
3-13 H/P OUT UNIT 1
4 00D1U-3777A ETHERNET UNIT 1 *
5 nsp MAIN CHASSIS 1 *
6 00D 104 0351 019 FOOT 4
7 00D 461 1066 002 FELT 4
8 nsp FRONT BRACKET 1 *
9 nsp CORD HOLDER (L50) 1
10 nsp LOCKING CARD SPACER 1
11 nsp SPACER 1
12 00D 399 1100 003 WLAN MODULE(13CH) for E2, JP 1
12 00D 399 1099 004 WLAN MODULE(11CH) for E3 1
13 nsp FFC ID SUB ASSY for E3 1 *
14 nsp PWB SUPPORT 1 *
15 nsp EARTH PLATE 1*
16 00D 105 1681 008 REAR PANEL 1*
17 00D 421 0851 003 FAN 2410RL04WS10 1 *
18 nsp FAN BRACKET 1 *
19 nsp FAN GUARD 1*
20 00D 216 0125 001 AM FM TUNER(E2) for E2 1
20 00D 216 0129 007 AM FM TUNER(E3 RDBS) for E3 1
20 00D 216 0127 009 AM FM TUNER(J) for JP 1
21 nsp ANNTENA CABLE 1
22 nsp SHIELD COVER 1 *
★ 23
nsp WIRE CLAMPER 1
24 00D 146 2488 104 INNER PANEL ASSY 1 *
24-1 - INNER PANEL 1*
24-2 - WINDOW 1*
25 00D 144 3013 103 FRONT PANEL ASSY 1 *
25-1 - FRONT PANEL L 1 *
25-2 - FRONT PANEL R 1 *
26 nsp EARTH BRACKET 2 *
