94
S-302
1U-3809A VIDEO P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 262 3495 003 ADV7403BSTZ-110
IC104,105 00D 263 1295 907 TA48018BF(T6L1,NQ) *
IC106 00D 263 1297 905 TA48033BF(T6L1,NQ) *
IC110 00D 263 1278 908 SI-8001FDE *
IC201 nsp EP2C35F484C8N
IC202 00D 262 3718 007 NT5DS16M16CS-6K
IC203 00D 262 3715 929 M25P64-VMF6TG(EE5B)
IC204 00D 262 3767 906 EPCS16SI16N/PT(GUI) *
IC205 00D 262 3714 904 FCXO-05(48.0MHZ) *
IC206 00D 262 3473 902 LP2995M
IC207 00D 263 1296 906 TA48025BF(T6L1,NQ)
IC208 00D 263 1272 904 LM2832XMY
IC209 00D 262 3754 906 CDCVF2505PWR
IC301 nsp FLI2310-LF-CF
IC302 00D 262 3598 007 K4S643232H-UC60
IC401 00D 262 3364 011 SII9030CTU-7
IC501,502 00D 262 3478 004 ADV7320
IC505 00D 262 3277 904 SN74LVC157APW-EL2 +C
IC507 00D 262 2977 917 BA25BC0FP-E2
IC509 00D 262 2977 917 BA25BC0FP-E2
IC510 00D 263 1296 906 TA48025BF(T6L1,NQ) *
IC511 00D 263 1282 907 BD7820FP-E2 *
IC601 00D 262 3551 002 NJW1321FP1
IC602 00D 263 1225 906 NJM2581M-TE1
IC604 00D 263 1295 907 TA48018BF(T6L1,NQ)
IC701,702 00D 262 3445 901 TC4051BFT
IC703 00D 262 3446 900 TC4052BFT
IC704 00D 262 3445 901 TC4051BFT
IC706 00D 263 1082 903 TK15420MTL +C
IC707 00D 263 1273 903 NJM2566AV
IC708 00D 263 1082 903 TK15420MTL +C
TR101 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR401 00D 275 0110 905 HN1K02FU-TE85L
TR501-505 00D 271 0293 901 2SA1022-B +C
TR601 00D 275 0110 905 HN1K02FU-TE85L
TR602 00D 271 0312 905 KTA1504S-GR-RTK/P
TR603 00D 269 0144 905 DTC114YKA-T146 +C
TR604 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR701,702 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR703 00D 271 0312 905 KTA1504S-GR-RTK/P
TR704,705 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR706 00D 271 0312 905 KTA1504S-GR-RTK/P
D101 00D 276 0794 900 KDS160-RTK/P
D103,104 00D 276 0794 900 KDS160-RTK/P
D105 00D 276 0827 903 SPB-G54SVR
D201 00D 276 0794 900 KDS160-RTK/P
D304 00D 276 0846 900 RB060M-30
D401-408 00D 276 0833 900 ESD PROTECTOR(6802)
D501 00D 276 0794 900 KDS160-RTK/P
D503 00D 276 0794 900 KDS160-RTK/P
D511,512 00D 276 0794 900 KDS160-RTK/P
D604 00D 276 0773 905 RB501V-40 +2125
