Dexter Laundry O Series User Manual

17
8514-300-001 REV PR
6.2 Express Vended Washer Specificaons
Express Vended Washers T-350 T-450 T-650 T-750
Capacity Dry Weight Capacity - lb (kg) 20 (9.1) 30 (13.6) 40 (18.1) 50 (22.7)
Cylinder Volume - cu ft (L) 2.7 (76.5) 3.8 (107.6) 6 (170) 6.5 (184.1)
Speed High Extract Speed - g (RPM) 200 (819) 200 (750) 200 (750) 200 (685)
Intermediate Extract Speed - g (RPM) 60 (449) 60 (411) 60 (411) 60 (375)
Washing Speed - g (RPM) 0.9 (55) 0.9 (50) 0.9 (50) 0.9 (43)
Motor Size - hp (kW) 1 (0.75) 2 (1.5) 2 (1.5) 3 (2.2)
Dimensions Cabinet Height - in (cm)
43
7/8 (111.4)
48
3/16 (122.4) 53 (134.6)
55
3/8 (140.7)
Cabinet Width - in (cm) 26 (66) 29 7/8 (75.9)
29
7/8 (75.9)
34
3/8 (87.3)
Cabinet Depth - in (cm) 28 (71.1) 28 1/4 (71.8)
38
1/8 (96.8)
32
7/8 (83.5)
Door Opening - in (cm)
12
1/4 (31.1) 15 1/4 (38.7)
15
1/4 (38.7)
19
1/4 (48.9)
Floor to Door Bottom - in (cm)
14
7/8 (37.8) 16 1/4 (41.3)
16
1/4 (41.3) 16 (40.6)
Cylinder Diameter - in (cm) 21 (53.3) 25 (63.5) 25 (63.5) 30 (76.2)
Cylinder Depth - in (cm)
13
1/2 (34.3) 13 3/8 (34)
21
1/8 (53.7) 16 (40.6)
Weight Net Weight - lb (kg) 383 (173.7) 526 (238.6) 744 (337.5) 925 (419.6)
Shipping Shipping Weight - lb (kg) 407 (184.6) 544 (246.8) 766 (347.5) 952 (431.8)
Shipping Height - in (cm)
49
1/4 (125.1) 53 1/4 (135.3)
58
3/4 (149.2)
61
1/2 (156.2)
Shipping Width - in (cm)
28
1/4 (71.8) 31 1/2 (80)
31
1/2 (80) 36 (91.4)
Shipping Depth - in (cm)
33
1/2 (85.1) 33 1/2 (85.1)
43
3/4 (111.1) 38 (96.5)
Water Water Inlet Size - in (mm) 3/4 (19) 3/4 (19) 3/4 (19) 3/4 (19)
Pressure (min-max) - psi (kPa)
30-
120
(207-
827) 30-120
(207-
827)
30-
120
(207-
827)
30-
120
(207-
827)
Flow Rate - gal/min (L/min) 9 (34) 9 (34) 9 (34) 9 (34)
Approx. Water Usage Per - gal (L) 15.8 (59.8) 22.2 (84) 35.1 (132.9) 38.4 (145.4)
Drain Diameter (O.D.) - in (cm) 2 1/4 (5.7) 3 (7.6) 3 (7.6) 3 (7.6)
Floor to Center of Drain - in (cm) 6 (15.2) 5 (12.7) 6 7/8 (17.5) 6 5/8 (16.8)
Electrical Volts / Hz / Phase / Wiring/Distribution System Circuit Breaker Amps / Running Amps / Wire Size
230 / 50 / 1 / 2 wire + ground / TN-S
15 / 6.2 / 3.5
mm² 15 / 6.2 / 3.5 mm²
15 / 6.2 / 3.5
mm²
20 / 8.4 / 3.5
mm²
Installation Min. Clearance Between Machines - in (cm) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3) 1/2 (1.3)
Min. Clearance Behind Machines - in (cm 24 (61) 24 (61) 24 (61) 24 (61)
Min. Concrete Thickness - in (cm) 6 (15.2) 6 (15.2) 8 (20.3) 8 (20.3)
Table 6-2 Express Vended Washer Specificaons
