Dexter Laundry O Series User Manual

20
8514-300-001 REV PR
WARNING
CARE MUST BE STRESSED WITH ALL
FOUNDATION WORK TO ENSURE A
STABLE UNIT INSTALLATION,
ELIMINATING POSSIBILITIES OF
EXCESSIVE VIBRATION.
Allow a minimum 610 mm (24 inches) of clearance behind the rear of the machine to provide
access for motor service.
Installation on an isolated pad is NOT recommended. Consult a structural engineer for
installations that will not be tied to a surrounding floor.
7.1.2 Mounng Height
A concrete pedestal or steel-mounting base that elevates the machine above the floor level is
suggested to provide easy access to the loading door.
Suggested Amount to Elevate Washer:
T-300/350: approximately 203 mm (8 inches)
T-400/450/600: approximately 152 mm (6 inches)
T-650/750/900: approximately 102 mm (4 inches)
T-350 SWD: approximately 203 mm (8 inches)
T-450 SWD: approximately 152 mm (6 inches)
Contact a Dexter laundry equipment distributor for recommended steel mounting bases.
Available steel mounting bases:
Washer Part Number Height
T-300 9945-094-003 203 mm (8 inches) Single Base
T-300 9945-094-004 203 mm (8 inches) Double Base
T-350 9945-121-001 203 mm (8 inches) Single Base
T-400 9945-089-001 152 mm (6 inches) Single Base
T-400 9945-089-002 152 mm (6 inches) Double Base
T-450 9945-123-001 152 mm (6 inches) Single Base
T-600 9945-098-001 152 mm (6 inches) Single Base
T-650 9945-145-001 152 mm (6 inches) Single Base
T-750 9945-117-001 152 mm (6 inches) Single Base
T-900 9945-103-001 103 mm (4 inches) Single Base
T-900 9945-118-001 152 mm (6 inches) Single Base
T-350 SWD 9945-151-001 6” (152 mm)
T-450 SWD 9945-110-001 4” (102 mm)
T-450 SWD 9945-111-001 6” (152 mm)
