Dexter Laundry T-350 User Manual

57
8514-300-001 REV PR
7.1.8 Plumbing
Water supply hoses are provided with each machine. The threaded connections on the hoses are
¾-14 BSP for 50 Hz models.
Separate hot and cold-water lines must be supplied to the machine, maintaining 207 kPa to 827
kPa (30 psi to 120 psi) water flow pressure. A 60°C (140°F) hot water supply is recommended for
best washing results. Do not exceed 82°C (180°F) water temperature.
7.1.9 Drain
The drain outlet tube size:
For T-300, 350 and 350 SWD is 57 mm (2 ¼ inches) in diameter,
and for all other models is 76 mm (3 inches) in diameter.
Any drain hose used must be lower than the drain valve to assure proper draining.
7.1.10 Protecve Film
The machine may have protective adhesive film on the front control panel label area and on the
front, top, and side stainless steel panels. The film may be peeled off before putting the
machine into service.
7.1.11 Electrical
INFORMATION
DISCONNECT WATER SUPPLY
BEFORE SERVICING
EQUIPMENT.
The Dexter washing machines are intended to be permanently installed appliances. No power
cord is provided. The machine should be connected to an individual branch circuit not shared by
lighting or other equipment. A means for disconnection with a contact separation of at least 3
mm (1/8 inches) must be provided.
Individual circuit breakers for each unit are required. Do not use ground-fault (earth-fault) circuit
breakers or ground-fault (earth-fault) circuit interrupter outlets, unless required by code. If local
codes require the use of residual current devices (RCD), the RCD must meet the following
requirements:
 Have no more than 2 machines installed on a 100mA RCD, or 1 machine on a 30mA RCD if
100mA is not allowed.
 Be of type B to allow for the use of DC voltages inside the machine.
The machine connection should be sheathed in liquid-tight or approved flexible conduit, or
equivalent, with conductors of the proper size and insulation. The sheath of the supply cable
must be at least equivalent to that of a cable complying with IEC 227 or IEC 245. A qualified
technician should make such connections in accordance with the wiring diagram. See
specification sheet for minimum recommended wire size. The voltage must not drop by more
than 5% between the supply and equipment being powered.
INFORMATION
DISCONNECT POWER
BEFORE SERVICING
EQUIPMENT.
