Digi ConnectCore Hardware Reference Manual

About the development board Analog video interface
ConnectCore for i.MX51 Hardware Reference Manual
119
Signal GPIO Jumper Comment
USER_BUTTON2 GPIO1_1 J29 10K pull-up to +2.775V on the development board
USER_LED2# GPIO3_9 J9
Analog video interface
Analog video connector, X32
The development board provides an Analog Video connector. This connector is a 15-pin female
connector, labeled X32. The Analog Video interface is connected to the Display 1 interface of the
i.MX51 CPU.
The table below shows the pinout of the Analog Video connector.
