Dingo K9-4 Operation & Maintenance Manual
21
Item Qty Dingo Part No Description
1 1 K94009 Welded Dash Assembly
2 1 330-003-008 Main Control Bank
3 1 330-003-051 Main remote bank
4 1 330-003-035 Pump Selector - SD4
5 1 330-003-052 Flow Control K94
6 1 331-203-002 In-line Check Valve
7 1 K94411 Flow Control To Remote Bank
8 1 K94412 Pipe (FP) - Flow Control To Pump Selector
9 1 K94413 Pipe (CD) - Main Bank To Dump
10 1 K94414 Pipe (AP) - Pump Selector To Remote Bank
11 1 K94033 Immobiliser Assembly
