Dingo K9-4 Operation & Maintenance Manual
35
Perkins Dash
Part Numbers
Item Qty Dingo Part No Description
1 1 K94009 Welded Dash Assembly
2 1 . Safety Shutdown
3 1 . .
4 1 518-000-024 Diode Fuel Stop Solenoid
5 1 . Voltage Regulator
6 1 . .
7 1 410-000-048 Hour Meter
8 1 K94043 Left Hand Handle Bar
9 1 K94044 Right Hand Handle Bar
10 2 043-000-043 Handle Grip
11 1 511-000-012 Throttle Cable Assembly
12 4 132-151-000 Spring Lock Washer M12
13 4 111-511-025 Hex Bolt M12 x 25
14 5 131-121-001 Plain Washer M6
15 5 132-211-000 Spring Lock Washer M6
16 1 111-211-012 Hex Bolt M6 x 12
17 1 121-121-000 Nut Hexagonal M6
18 5 111-211-020 Hex Bolt M6 x 20
19 2 122-121-000 Nyloc Nut M6
20 1 021-000-024 K94 Compliance Plate
21 4 100-000-027 Type U Drive Screws 6 x 1/4” ZP
22 1 410-000-154 Fuse Block - 4 Blade With Buzz Bar
23 1 . .
24 2 410-000-141 20 Amp Fuse
25 1 410-000-120 15 Amp Fuse
26 2 100-000-061 M6 Button Head Screw
27 1 111-211-035 Hex Bolt M6 x 35
28 1 410-000-059 40 Amp 5 Pin Starter Relay
