Dingo K9-4 Operation & Maintenance Manual
41
Series II From June 2003 To January 2005 Fibre Glass Fuel Tank
Item Qty Dingo Part No Description
1 1 043-300-002 Fibre Glass L/H Panel
2 1 043-300-003 Fibre Glass R/H Panel
3 1 516-000-037 Fuel Tank (Fibre Glass) With Fuel Light 06/2003-01/2005
4 1 043-300-001 Dash Panel (Fibre Glass)
5 1 043-300-024 Bonnet With Scoop (Fibre Glass) After 06/2003.Use Bonnet With Scoop
6 1 K94-099 Bonnet Gauze
7 1 043-300-014 Hinged Bonnet Handle
8 2 043-300-012 Relief Valve Blanking Grommet
9 1 410-000-152 3rd Gear Switch
10 1 410-000-116 12 Volt Auxiliary Power
11 1 410-000-150 Low Fuel Light
12 1 410-000-089 Engine Warning Light.Bulb:420-000-111
13 1 043-000-044 Kohler Ignition Barrel
13 1 518-000-045 Yanmar Ignition Barrel
14 1 043-000-047 Kohler Key
14 1 518-000-046 Yanmar Key
15 1 043-300-013 Immobilizer Grommet
16 3 043-300-017 Bonnet Rest Lugs
17 1 516-000-035 Fuel Cap
18 1 410-000-149 Low Fuel Light Sensor Internal
19 2 516-000-026 Fuel Tank Fitting Bungs
20 1 516-000-029 Petrol Fuel Brass Fitting
21 1 K94-380 Petrol Fuel Tank Blanking Bung
22 2 516-000-030 Diesel Fuel Brass Fitting
Plastic Fuel Tank January 2005-Onwards
Item Qty Dingo Part No Description
1 1 043-300-002 Fibre Glass L/H Panel
2 1 043-300-003 Fibre Glass R/H Panel
3 1 K94-520 Fuel Tank (Plastic) After 01/2005
4 1 043-300-001 Dash Panel (Fibre Glass)
5 1 043-300-024 Bonnet With Scoop (Fibre Glass) After 06/2003
6 1 K94-099 Bonnet Gauze
7 1 043-300-014 Hinged Bonnet Handle
8 2 043-300-012 Relief Valve Blanking Grommet
9 1 410-000-152 3rd Gear Switch
10 1 410-000-116 12 Volt Auxiliary Power
11 1 410-000-150 Low Fuel Light
12 1 410-000-089 Engine Warning Light.Bulb:420-000-111
13 1 043-000-044 Kohler Ignition Barrel
13 1 518-000-045 Yanmar Ignition Barrel
14 1 043-000-047 Kohler Key
14 1 518-000-046 Yanmar Key
15 1 043-300-013 Immobilizer Grommet
16 3 043-300-017 Bonnet Rest Lugs
17 1 516-000-035 Fuel Cap
18 1 K94-642 Low Fuel Light Sensor Screw In
19 2 516-000-026 Fuel Tank Fitting Grommet
20 1 516-000-029 Petrol Fuel Brass Fitting
21 1 K94-380 Petrol Fuel Tank Blanking Bung
22 2 516-000-030 Diesel Fuel Brass Fitting
