Dingo K9-4 Operation & Maintenance Manual
39
K9-4 Arm Assembly Part Number
Item Qty Dingo Part No Description
1 1 K94207 K94 Load Arm Assembly Series II (New)
2 1 K94212 Mount Plate (See Previous Page)
3 10 132-221-000 Spring Lock Washer M8
4 10 111-311-016 Hex Bolt M8 x 16
5 2 K94230 Tie Down Bracket
6 2 330-000-018 15mm Hose Guide Plastic
7 1 330-000-020 22m Hose Guide Plastic
8 1 K94237 22mm Hose Guide Plate
9 1 K94434 15mm Hose Guide Plate
10 1 K94433 Remote & Crowd Hose Spacer
11 2 111-311-060 Hex Bolt M8 x 60
12 4 131-231-000 Plain Washer M10
13 4 132-141-000 Spring Lock Washer M10
14 4 111-411-025 Hex Bolt M10 x 25
15 2 K94027 Clevis Pin - Arms To Top of Chassis
16 3 321-000-005 Lift Cylinder
17 6 315-595-500 90 Degree Ram Fitting (C59-0909)
18 1 K94039 Clevis Pin - Top Crowd Pin Chrome
19 2 D95034 Clevis Pin - Lower Lift Arms Chrome
20 2 043-300-021 Arm - Plastic Blanking Grommet
21 1 318-132-000 1/2” Female Quick Release Coupling (NV12GASF)
22 1 318-131-000 1/2” Male Quick Release Coupling (NV12GASM)
23 1 318-122-000 3/8” Female Quick Release Coupling (NV38GASM)
24 1 318-121-000 3/8” Male Quick Release Coupling (NV38GASF)
25 1 310-400-002 1/2” Male Coupling Plug
26 1 310-400-001 1/2” Female Coupling Plug
27 1 310-300-000 3/8” Female Coupling Plug
28 1 310-300-001 3/8” Male Coupling Plug
29 2 316-754-700 Hydraulic Fitting (ZCR2-1408)
30 2 316-753-700 Hydraulic Fitting (ZCR2-0906)
31 2 K94105 Clevis Pin - Top Lift Ram Pin Chrome
32 4 043-000-057 Duralon Bush 1 1/4”
34 1
K94440 1/4” Hyd-Hose RH Ram Bottom To Control Bank Top (520mm)
35 1 K94441 1/4” Hyd-Hose RH Ram Top To Control Bank Bottom (430mm)
36 1 K94442 1/4” Hyd-Hose LH Ram Bottom To Control Bank Top (395mm)
37 1 K94443 1/4” Hyd-Hose LH Ram Top To Control Bank Bottom (355mm)
38 1 K94448 1/4” Hyd-Hose Crowd Ram Bottom To Front Fitting (1590mm)
39 1 K94449 1/4” Hyd-Hose Crowd Ram Top To Rear Fitting (1500mm)
40 1 K94450 1/2” Hyd-Hose 1/2” Female Quick Release To Front Fitting (1150mm)
41 1 K94451 1/2” Hyd-Hose 1/2” Male Quick Release To Rear Fitting (1180mm)
42 1 K94452 1/4” Hyd-Hose 3/8” Female Quick Release To Front Fitting (1105mm)
43 1 K94453 1/4” Hyd-Hose 3/8” Male Quick Release To Rear Fitting (1130mm)
To Next Page
