DL06K Interim Tire-4 Diesel Engine Safety Regulations & Specifications
13
1.2. Engine Specifications
Engine model
Items
DL06K
LDF00/LDF01
Engine type
Water-cooled, 4 cycle, In-line,
Turbo charged & inter-cooled
Combustion chamber type Direct injection type
Cylinder liner type Replaceable dry liner
Timing gear system Gear driven type
No. of piston ring 2 compression ring, 1 oil ring
No. of cylinder-bore x stroke (mm)
6 – 100 ×125
Total piston displacement (cc) 5,890
Compression ratio 17.4 : 1
Engine dimension
(length x width x height) (mm)
1,264 x 848 x 1,124
weight (kg) 644
Rotating direction (from flywheel) Counter clockwise
Firing order 1 – 5 – 3 – 6 – 2 - 4
Fuel high pressure pump type Bosch CP3.3 fuel high pressure pump type
Engine control type Electric control type (ECU)
Injector type Multiple hole type
Fuel injection operating pressure (bar) 1,800
Valve clearance (cold)
(mm)
Intake valve 0.3
Exhaust valve 0.4
Intake valve
Open at
21° (B.T.D.C)
Close at
33° (A.B.D.C)
Exhaust valve
Open at
56.2° (B.B.D.C)
Close at
22.2° (A.T.D.C)
Fuel filter type Current type (cartridge type)
Oil pressure
(kg/cm
2
)
At idle speed 1.5 or more
At rated speed 3.0 ~ 6.0
Using lubrication oil SAE 15W40 (over API CJ-4 or ACEA-E9 class)
Lubrication method Full forced pressure feed type
Oil pump type Gear type driven by crankshaft
Oil filter type Cartridge type
Lubricating oil capacity (max./min.)
1
(lit) 27 / 17
Oil cooler type Water cooled
Oil pressure indicator Hydraulic indicator
Water pump Belt-driven centrifugal type
Cooling method Pressurized circulation
Oil separator OCV
Cooling water capacity (engine only) (lit) 13
1)
With 2.0 liters in the engine
