DL06K Interim Tire-4 Diesel Engine Safety Regulations & Specifications
14
Engine model
Items
DL06K
LDF00/LDF01
Thermostat
Type Wax pallet type
Open at (°C)
75
Open wide at (°C)
90
Valve lift (mm) 9.5
Water temperature indicator Water temperature sensor mounted
Turbo charger Exhaust gas driven type
Engine stop system Fuel feeding shut-off by ECU
Alternator (voltage – capacity) (V–A) 24 - 50
Starting motor(voltage–output) (V–kW) 24 – 4.5
Air heater (V–A) 24 – 2.1
1.3. Engine Power
tolerance : ±5%
Engine model Performance
1)
Model Suffix
Power
(PS / rpm)
Torque
(kg.m / rpm)
Low idle
(rpm)
High idle
(rpm)
DL06K
LDF00 140/2,100 65/1,400 850
±10 2,400±25
LDF01 160/2,100 74/1,400 850±10 2,400±25
* Note1) : All data are based on operation without cooling fan.
