DL06K Interim Tire-4 Diesel Engine Safety Regulations & Specifications
17
1.5. Engine Assembly
1.5.1. Sectional drawing
1 Cooling water pump 8 Cylinder head
2 Thermostat 9 Vibration damper
3 Exhaust valve 10 Oil pan
4 Intake valve 11 Oil suction pipe
5 Piston 12 Connecting rod
6 Cylinder head cover 13 Camshaft
7 Intermediate cover 14 Tappet
9 10 11 121314
123 45 6 7 8
EL4OM003
