Dover Dow-Key Microwave MS Matrix Series User Manual

61
Appendix A
Technical Specifications
Model: MP-2U18S-30-GPIB
Configuration: 4 SP10T switches mounted on the rear panel
connected in a 1x30 multiplexing configuration
RF Connectors: SMA (on rear panel)
Frequency range: DC to 18 GHz
Return loss (VSWR)
Insertion loss
Isolation
RF Power:
Frequency(GHz): DC‐4 4‐8 8‐12.4 12.4‐18
VSWR(Ratiomax): 1.30:1 1.35:1 1.50:1 1.80:1
InsertionLoss(dBmax): 1.0 1.5 1.5 2.0
Isolation(dBmin): 70 65 60 55
RFPower(WattsCWmax): 100 70 60 50
Impedance: 50 Ω
Switching Speed: 50ms (per switch)
Operating Temp: 0 to 50 degrees C
Switch Type: Four normally open SP10T.
Switch p.n. 5A1-520802N-ROHS
Line Voltage: 120-240 VAC, 50-60 Hz
Control Interfaces: GPIB (IEEE 488) Connector
RS-232 via 9-pin D-Sub female connector
CAN Bus via 4 pin XLR female connector
USB type A (used as ‘virtual’ serial port)
RS-232 Settings: Settable at 1200, 2400, 4800, 9600 (default),
19200, 38400, 57600,115200 bits/sec,
8 bit data, no parity, 1 stop bit
Dimensions: 3.5” H x 19” W x 15.625” D (without handles)
