Safety
Weight of the child/indicative age
Seat position
Front passenger
airbag
Under 13 kg
(groups 0
(b) and
0+)
Up to about 1 year
From 9 to 18 kg
(group 1)
From about 1 to
3
years old
From 15 to 25 kg
(group 2)
From about 3 to
6
years old
From 22 to 36 kg
(group 3)
From about 6 to
10
years old
Row 1
(c)
Passenger seat
with height
adjustment (d)
or without height
adjustment (e)
Deactivated
"OFF"
U U U U
Activated "ON" X UF UF UF
Row 2 (f)
Side rear seats
Centre rear seat (g)
U U U U
U: seat position suitable for installing
a child seat secured using the seat belt
and universally approved for "rearward
facing" and/or "forward facing" use.
UF: seat suitable for installing a
child
seat secured using the seat belt and
universally approved for "forward facing"
use.
X: seat position not suitable for installing
a child seat of the weight group indicated.
(a) Universal child seat: child seat that can
be installed in all vehicles using the seat
belt.
(b) Group 0: from birth to 10
kg. Carrycots
and "car" infant carriers cannot be
installed on the front passenger seat.
(c) Refer to the current legislation in your
country before installing your child on
this seat.
(d) The front height-adjustable seat must
be adjusted to the highest and fully back
longitudinal position.
(e) The backrest must be in an upright
position.
(f) To install a
child seat at the rear,
"rearward facing" or "forward facing",
move the front seat forward, then adjust
the backrest to an upright position to
allow enough room for the child seat and
the child's legs.
(g) A child seat with a
support leg must never
be installed on the centre rear passenger
seat.
