94
05
Safety
i-Size child seats
In accordance with the new European regulations, this table indicates the options for installing
i-Size child seats on seats in the vehicle fitted with ISOFIX mountings approved for i-Size.
Seat position
Front passenger
airbag
i-Size restraint
system
Row 1
(a) Passenger seat with height
adjustment or without height
adjustment (b)
Deactivated: "OFF" i-U
Activated: "ON" i-UF
Row 2 Rear side seats (c) i-U
Rear centre seat Not i-Size
i-U: suitable for i-Size restraint systems in
the "Universal" category, forward facing
and rearward facing.
i-UF: only suitable for i-Size restraint systems
in the "Universal" category which are
forward facing.
(a) Refer to the current legislation in your
country before installing a child at this
seat position.
(b) The front height-adjustable seat must
be adjusted to the highest and fully
back longitudinal position.
(c) If it is the passenger's seat, the
front height-adjustable seat must
be adjusted to the highest and fully
forward longitudinal position, with the
backrest straightened; if it is the driver's
seat, highest and mid-runner position,
backrest straightened.
i-Size child seats have two latches that engage
on the two rings A.
These i-Size child seats also have:
-
either an upper strap that is attached to ring
B,
-
or a
support leg that rests on the vehicle
floor, compatible with the approved i-Size
seat position,
the role of which is to prevent the child seat
from tipping forward in the event of a
collision.
For more information on the ISOFIX
mountings, refer to the corresponding section.
(a) Refer to the current legislation in your
country before installing a child at this
seat position.
(b) Remove the head restraints.
(c) Adjust the height-adjustable front driver
seat to the maximum height position.
(d) Adjust the front passenger seat to the
fully forward longitudinal position.
(e) The installation of a
carrycot on this seat
may prevent the use of one or more of
the other seats in this row.
