DSC Neo User Manual

Section 5: Programming
[106] – HSM2Host
[108] – HSM2955
[109] – Power Supply
[110] – 4 High Current Output
To confirm a module:
1. Enter section [903]>[000] to view all enrolled modules or scroll to the module type you want to confirm (101-110).
2. Press [*] to select the module type then scroll to the specific module you want to confirm. Press [*] to enter Confirmation
mode. The module’s serial number and slot number are displayed on the keypad and the status LEDs on the device flash.
This continues until confirmation mode for the device is exited via the [#] key.
Note: Keypad Blanking (section [016], option 3) must be disabled to confirm keypads.
Note: When using an LEDor ICONkeypad, use the following table to match the number displayed on the keypad to a mod-
ule.
Table 5-4 Module numbers when programming with an LEDor ICON keypad
#displayed on keypad Model # Description
18 HSM2108 Neo 8 zone expander module
19 HSM2HOST Neo PowerG wireless tranceiver module
24 HSM2204 Neo 4 high current output module
28 HSM2208 Neo 8 output expander module
30 HSM2300 Neo 1A power supply module
50 HS2LCD Neo 2x16 LCD keypad
51 HS2ICN Neo Icon Keypad
52 HS2LCDP Neo 2x16 LCD keypad with Prox
53 HS2ICNP Neo Icon Keypad with Prox
56 HS2LED Neo 16 LED keypad
57 HS2TCHP Neo Touchscreen Keypad with Prox
59 HS2LCDRF Neo 2x16 LCD RFK keypad
5A HS2ICNRF Neo Icon RFK Keypad
5B HS2LCDRFP Neo 2x16 LCD RFK keypad with Prox
5C HS2ICNRFP Neo Icon RFK Keypad with Prox
60 HS2LCDWF Neo 2x16 LCD wirefree keypad
67 HS2TCHWF Neo Touchscreen wirefree Keypad
6B HS2LCDWFP Neo 2x16 LCD wirefree keypad with Prox
6D HS2LCDWFPV Neo 2x16 LCD wirefree keypad with Prox and Voice
95 HSM2955 Neo Audio alarm verification module
96 HSM2955R Neo Audio alarm verification module with Recording
5.3.21 Testing
[904] Wireless Placement Test
This test is used to determine RF signal status for wireless devices and can be performed at a system keypad or at the indi-
vidual device. These instructions pertain to testing at the keypad. For instructions on placement testing at the device, refer to
the installation sheet included with the wireless equipment.
The following test modes are available:
- 119 -
