Section 6: Programming Worksheets
(3 digit decimal) 001 - Virtual Input 1: 017 - Virtual Input 17:
002 - Virtual Input 2: 018 - Virtual Input 18:
Description on page 115 003 - Virtual Input 3: 019 - Virtual Input 19:
Default: 000 004 - Virtual Input 4: 020 - Virtual Input 20:
005 - Virtual Input 5: 021 - Virtual Input 21:
006 - Virtual Input 6: 022 - Virtual Input 22:
007 - Virtual Input 7: 023 - Virtual Input 23:
008 - Virtual Input 8: 024 - Virtual Input 24:
009 - Virtual Input 9: 025 - Virtual Input 25:
010 - Virtual Input 10: 026 - Virtual Input 26:
011 - Virtual Input 11: 027 - Virtual Input 27:
012 - Virtual Input 12: 028 - Virtual Input 28:
013 - Virtual Input 13: 029 - Virtual Input 29:
014 - Virtual Input 14: 030 - Virtual Input 30:
015 - Virtual Input 15: 031 - Virtual Input 31:
016 - Virtual Input 16: 032 - Virtual Input 32:
6.13 Schedule Programming
[601] Programming Schedule 1
Description on page 63
Interval 1 101 – Start Time: 102 – End Time:
103 – Days Assignment: 104 – Holiday Assignment:
(4- digit decimal) 01 – o Sunday o Holiday 1
HH:MM 02 – o Monday o Holiday 2
to HH:MM 03 – o Tuesday o Holiday 3
Default: 0000 04 – o Wednesday o Holiday 4
05 – o Thursday
06 – o Friday
07 – o Saturday
Interval 2 201 – Start Time: 202 – End Time:
203 – Days Assignment: 204 – Holiday Assignment:
(4- digit decimal) 01 – o Sunday o Holiday 1
HH:MM 02 – o Monday o Holiday 2
to HH:MM 03 – o Tuesday o Holiday 3
Default: 0000 04 – o Wednesday o Holiday 4
05 – o Thursday
06 – o Friday
07 – o Saturday
Interval 3 301 – Start Time: 302 – End Time:
- 167 -
