5.2 Exposure switch
The capture ring can be used as alternative to
using the control panel to activate the irradiation.
5.3 Radiation field limitation
The radiation field collimitation reduces the useful
x-ray field to the required dimensions. This
reduces the x-ray exposure of the patient. Com-
ply with any national regulations.
5.4 Wall mounting plate
The wall mounting plate can be installed if
required in order to ensure the holding forces of
the fittings. The unit should be fixed to the wall
mounting plate using the four screws provided.
5.5 Adapter plate
The adapter plate is mounted if necessary. The
already available drill holes of products from other
manufacturers are used for attaching. The unit is
fixed to the adapter plate using the four screws
provided.
Product description
16 2202100028L02 2007V019
EN
