Before initial start-up check that the mains sup-
ply voltage and the voltage stated on the type
plate match (see also "4. Technical data").
7.5 Connecting the unit to the
mains supply
Requirements:
ü
Correctly installed mains cable available at the
height of the wall mounting plate, or easily-
accessible power outlet.
ü
Mains voltage must match the information
shown on the type plate of the power supply
unit.
❯
Connect up the lines.
8 Commissioning
NOTICE
Short circuit due to the build up of
condensation
❯
Do not switch on the unit until it has
warmed up to room temperature and it
is dry.
The required tests (e.g. acceptance tests) must
be carried out in accordance with local rules and
regulations.
❯
Find out which tests are required.
❯
Carry out testing in accordance with local rules
and regulations.
8.1 Acceptance test
The Intra / Extra Digital test body is
required for acceptance tests with the
image plate and sensor as receivers, and
possibly also the corresponding test body
holder.
❯
Before the unit is started up and used for the
first time, the acceptance test of the X-ray sys-
tem must be carried out in accordance with
national regulations.
The consistency tests, which must be carried
out at regular intervals by the dental professio-
nal, are based on the results of the acceptance
test.
8.2 Electrical safety checks
❯
Carry out the electrical safety check according
to the national law (e. g. in accordance with
IEC 62353).
❯
Document the results.
8.3 Switch on the unit.
The display will show the standard values for x-
ray exposures or the setting values used for the
last exposure carried out.
– Operational display lamps
– LED for tooth symbol selection
– LED for menu Adult/Child selection and the
– LED for image plate/sensor selection illumi-
nate.
Assembly
2202100028L02 2007V019 19
EN
