Eaton Cutler-Hammer Easy-Start ES Series User Manual

Easy-Start ES Instruction Manual
Drawings
INSTALLATION
2-35
.31
NOTES
1. EACH INCOMING LINE CABLE MUST PASS
THRU THE CORRESPONDING CURRENT
TRANSFORMER.
2. PANEL MATERIAL: 14 GA (.074) STEEL
FINISH: ASA 61 LIGHT GRAY
3. PANEL SHOULD BE MOUNTED IN A VERTICAL
POSITION TO PROVIDE PROPER COOLING.
4. USER MUST PROVIDE LOAD LUGS.
5. WHEN DAUGHTER BD. OPTION IS USED DEPTH
IS 7.50".
FIELD WIRING LUGS
WIRE GAUGE RANGE
LINE / LUGS
AWG #6-250MCM AWG 14-2
60
GROUND LUGS
MODEL
ES120-_EC
WEIGHT
LBS
.68
.000
6.38
12.38
18.38
8.63
24.38
27.00
26.50
0.00
.75
3.88
10.13 13.25
2.00
.257 DI A
0.00 3.75 6.25
.25
.38
0
9.25
13.69 14.00
4.75
Easy ES-016
Dimension and Installation Open Panel Slim Line Motor Control Center
ES120-_EC
Figure 2-16
