Eaton Cutler-Hammer Easy-Start ES Series User Manual

Easy-Start ES Instruction Manual
Operation
SECTION 3
3-9
DIP Switch Settings
DIP Switch Ampere Settings ES750
Table 3-11
DIP Switch Ampere Settings ES950
Table 3-12
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 211.5 185.3 167.5 150.8 133.9 122.9 114.8 106.6
0 0 0 1 273.0 240.5 218.1 197.1 175.5 161.6 151.2 140.6
0 0 1 0 324.0 286.7 260.8 236.2 211.2 194.7 182.4 170.1
0 0 1 1 375.8 334.0 305.1 276.9 248.4 229.6 215.3 201.0
0 1 0 0 408.0 363.9 332.9 302.7 272.1 251.7 236.6 221.1
0 1 0 1 453.8 406.1 372.5 340.3 306.3 284.0 267.3 250.0
0 1 1 0 492.0 441.8 406.4 372.0 336.0 311.9 293.7 275.0
0 1 1 1 531.8 479.6 441.9 405.2 366.9 341.4 322.2 302.0
1 0 0 0 557.3 503.8 465.3 427.4 387.3 361.1 340.5 319.9
1 0 0 1 592.5 537.4 497.1 458.0 415.9 388.1 366.8 344.8
1 0 1 0 622.5 565.9 524.8 484.3 441.4 412.1 389.7 366.7
1 0 1 1 653.3 595.8 553.3 511.5 467.1 437.0 414.2 390.0
1 1 0 0 672.8 614.2 571.8 529.5 483.7 452.8 429.2 405.0
1 1 0 1 700.5 641.7 598.2 554.8 507.9 476.3 451.8 426.6
1 1 1 0 725.3 665.8 621.5 577.3 529.4 497.5 472.1 446.0
1 1 1 1 750.0 690.0 645.0 600.8 552.0 519.0 493.5 466.5
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 267.9 234.7 212.2 191.0 169.6 155.6 145.5 135.0
0 0 0 1 345.8 304.6 276.3 249.7 222.3 204.7 191.6 178.1
0 0 1 0 410.4 363.2 330.4 299.2 267.6 246.7 231.1 215.5
0 0 1 1 476.0 423.1 386.5 350.8 314.6 290.8 272.7 254.6
0 1 0 0 516.8 461.0 421.7 383.5 344.7 318.9 299.7 280.1
0 1 0 1 574.8 514.4 471.9 431.1 388.0 359.8 338.5 316.7
0 1 1 0 623.2 559.6 514.8 471.1 425.6 395.1 372.1 348.4
0 1 1 1 673.6 607.5 559.7 513.2 464.7 432.4 408.2 382.6
1 0 0 0 705.9 638.1 589.4 541.4 490.6 457.4 431.3 405.2
1 0 0 1 750.5 680.7 629.7 580.1 526.9 491.6 464.6 436.8
1 0 1 0 788.5 716.7 664.7 613.5 559.0 522.0 493.6 464.4
1 0 1 1 827.5 754.6 700.9 647.9 591.6 553.6 524.6 494.0
1 1 0 0 852.2 778.0 724.3 670.6 612.7 573.5 543.7 513.0
1 1 0 1 887.3 812.8 757.8 702.7 643.3 603.4 572.3 540.4
1 1 1 0 918.7 843.3 787.3 731.2 670.6 630.2 598.0 565.0
1 1 1 1 950.0 874.0 817.0 761.0 699.2 657.4 625.1 590.9
