Eaton Cutler-Hammer Easy-Start ES Series User Manual

Available Options
Circuit Breakers
Thermal-Magnetic Breaker
Table 4-1
(1) All ratings shown above for HFD type can be used with either ES045 or ES070 models. Magnetic
trip adjust is not available on HFD type. Magnetic trip is set at approximately 10 times the circuit
breaker trip rating.
(2) All ratings shown above for HKD type can be used with either ES180, 250 or ES260 models.
(3) Adjustable rating plug 400-800 Amps.
(4) Adjustable rating plug 600-1200 Amps.
(5) When adjustable rating plugs are used, short delay pickup (magnetic) settings track the selected
position of the adjustable rating plug. For example, with an adjustable 800 amp rating plug set at
50%, and the short delay pickup (magnetic) set at 4X, the short delay pickup is 800 x 50% x
4=1600 amps.
Easy-Start ES Instruction Manual
Options
SECTION 4
4-5
Option No. With Mag. Nominal HP
Thermal Shunt Easy-Start Frame Breaker Trip
Magnetic Trip ES Model Size Type Amps Adj.
208 460
230V 575V
C01 C30 ES045(1) F HFD 30 (1)--- 5 15
C02 C31 ES045(1) F HFD 60 (1)--- 15 30
C03 C32 ES070(1) F HFD 100 (1)--- 20 40
C22 C51 ES070(1) F HFD 150 (1)--- 25 50
C04 C33 ES120 J HJD 150 5X-10X 25 50
C05 C34 ES120 J HJD 200 5X-10X 40 75
C06 C35 ES120 J HJD 250 5X-10X 50 100
C07 C36 ES180(2) K HKD 200 5X-10X 40 75
C08 C37 ES180(2) K HKD 250 5X-10X 50 100
C09 C38 ES180(2) K HKD 300 5X-10X 75 150
C10 C39 ES250(2) K HKD 400 5X-10X 100 200
C10 C39 ES260(2) K HKD 400 5X-10X 100 200
C11 C40 ES360 MC HMC 800 (3) 3X-10X (5) 150 300
C11 C40 ES500 MC HMC 800 (3) 3X-10X (5) 200 450
C11 C40 ES560 MC HMC 800 (3) 3X-10X (5) 200 450
C12 C41 ES750 NC HNC 1200 (4) 2X-8X (5) 300 600
C13 C42 ES950 NC HNC 1200 (4) 2X-8X (5) 400 800
