Easy-Start ES Instruction Manual
Operation
SECTION 3
3-8
DIP Switch Settings
DIP Switch Ampere Settings ES500
Table 3-9
DIP Switch Ampere Settings ES560
Table 3-10
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 141.0 123.5 111.7 100.5 89.3 81.9 76.6 71.1
0 0 0 1 182.0 160.3 145.4 131.4 117.0 107.7 100.8 93.7
0 0 1 0 216.0 191.2 173.9 157.5 140.8 129.8 121.6 113.4
0 0 1 1 250.5 222.7 203.4 184.6 165.6 153.1 143.5 134.0
0 1 0 0 272.0 242.6 222.0 201.8 181.4 167.8 157.8 147.4
0 1 0 1 302.5 270.7 248.4 226.9 204.2 189.4 178.2 166.7
0 1 1 0 328.0 294.5 270.9 248.0 224.0 208.0 195.8 183.4
0 1 1 1 354.5 319.8 294.6 270.1 244.6 227.6 214.8 201.4
1 0 0 0 371.5 335.8 310.2 284.9 258.2 240.7 227.0 213.2
1 0 0 1 395.0 358.3 331.4 305.3 277.3 258.7 244.5 229.9
1 0 1 0 415.0 377.2 349.8 322.9 294.2 274.7 259.8 244.4
1 0 1 1 435.5 397.2 368.9 341.0 311.4 291.3 276.1 260.0
1 1 0 0 448.5 409.5 381.2 353.0 322.5 301.8 286.1 270.0
1 1 0 1 467.0 427.8 398.8 369.9 338.6 317.6 301.2 284.4
1 1 1 0 483.5 443.9 414.4 384.9 353.0 331.7 314.8 297.4
1 1 1 1 500.0 460.0 430.0 400.5 368.0 346.0 329.0 311.0
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 157.9 138.3 125.1 112.6 100.0 91.8 85.8 79.6
0 0 0 1 203.8 179.6 162.9 147.2 131.1 120.7 112.9 105.0
0 0 1 0 241.9 214.1 194.7 176.4 157.7 145.4 136.2 127.0
0 0 1 1 280.6 249.4 227.8 206.8 185.5 171.4 160.8 150.1
0 1 0 0 304.6 271.7 248.6 226.0 203.2 188.0 176.7 165.1
0 1 0 1 338.8 303.2 278.2 254.1 228.7 212.1 199.6 186.7
0 1 1 0 367.4 329.9 303.4 277.7 250.9 232.9 219.3 205.4
0 1 1 1 397.0 358.1 329.9 302.5 274.0 254.9 240.6 225.5
1 0 0 0 416.1 376.1 347.4 319.1 289.2 269.6 254.2 238.8
1 0 0 1 442.4 401.3 371.2 342.0 310.6 289.8 273.8 257.5
1 0 1 0 464.8 422.5 391.8 361.6 329.5 307.7 291.0 273.8
1 0 1 1 487.8 444.8 413.1 381.9 348.7 326.3 309.2 291.2
1 1 0 0 502.3 458.6 427.0 395.3 361.2 338.1 320.5 302.4
1 1 0 1 523.0 479.1 446.7 414.2 379.2 355.7 337.4 318.5
1 1 1 0 541.5 497.1 464.1 431.0 395.3 371.5 352.5 333.0
1 1 1 1 560.0 515.2 481.6 448.6 412.2 387.5 368.5 348.3
