Eaton Cutler-Hammer Easy-Start ES Series User Manual

Easy-Start ES Instruction Manual
Operation
SECTION 3
3-7
DIP Switch Settings
DIP Switch Ampere Settings ES260
Table 3-7
DIP Switch Ampere Settings ES360
Table 3-8
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 73.3 64.2 58.1 52.3 46.4 42.6 39.8 37.0
0 0 0 1 94.6 83.4 75.6 68.3 60.9 56.0 52.4 48.7
0 0 1 0 112.3 99.4 90.4 81.9 73.2 67.5 63.2 59.0
0 0 1 1 130.3 115.8 105.8 96.0 86.1 79.6 74.6 69.7
0 1 0 0 141.4 126.2 115.4 104.9 94.3 87.3 82.0 76.7
0 1 0 1 157.3 140.8 129.1 118.0 106.2 98.5 92.6 86.7
0 1 1 0 170.6 153.2 140.9 128.9 116.5 108.1 101.8 95.3
0 1 1 1 184.3 166.3 153.2 140.5 127.2 118.3 111.7 104.7
1 0 0 0 193.2 174.6 161.3 148.2 134.3 125.2 118.0 110.9
1 0 0 1 205.4 186.3 172.3 158.8 144.2 134.5 127.1 119.5
1 0 1 0 215.8 196.2 181.9 167.9 153.0 142.9 135.1 127.1
1 0 1 1 226.5 206.5 191.8 177.3 161.9 151.5 143.6 135.2
1 1 0 0 233.2 212.9 198.2 183.5 167.7 157.0 148.8 140.4
1 1 0 1 242.8 222.4 207.4 192.3 176.1 165.1 156.6 147.9
1 1 1 0 251.4 230.8 215.5 200.1 183.5 172.5 163.7 154.6
1 1 1 1 260.0 239.2 223.6 208.3 191.4 179.9 171.1 161.7
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 101.5 88.9 80.4 72.4 64.3 59.0 55.1 51.2
0 0 0 1 131.0 115.4 104.7 94.6 84.3 77.6 72.6 67.5
0 0 1 0 155.5 137.6 125.2 113.4 101.4 93.5 87.6 81.6
0 0 1 1 180.4 160.3 146.5 132.9 119.2 110.2 103.3 96.5
0 1 0 0 195.8 174.7 159.8 145.3 130.6 120.8 113.6 106.1
0 1 0 1 217.8 194.9 178.8 163.4 147.0 136.3 128.3 120.0
0 1 1 0 236.2 212.1 195.1 178.5 161.3 149.7 141.0 132.0
0 1 1 1 255.2 230.2 212.1 194.5 176.1 163.9 154.7 145.0
1 0 0 0 267.5 241.8 223.3 205.2 185.9 173.3 163.4 153.5
1 0 0 1 284.4 258.0 238.6 219.8 199.6 186.3 176.0 165.5
1 0 1 0 298.8 271.6 251.9 232.5 211.8 197.8 187.0 176.0
1 0 1 1 313.6 286.0 265.6 245.5 224.2 209.8 198.8 187.2
1 1 0 0 322.9 294.8 274.5 254.1 232.2 217.3 206.0 194.4
1 1 0 1 336.2 308.0 287.1 266.3 243.8 228.6 216.9 204.8
1 1 1 0 348.1 319.6 298.3 277.1 254.1 238.8 226.6 214.1
1 1 1 1 360.0 331.2 309.6 288.4 265.0 249.1 236.9 223.9
