Eaton Cutler-Hammer Easy-Start ES Series User Manual

Easy-Start ES Instruction Manual
Operation
SECTION 3
3-3
DIP Switch Settings
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 0.282 0.247 0.223 0.201 0.179 0.164 0.153 0.142
0 0 0 1 0.364 0.321 0.291 0.263 0.234 0.215 0.202 0.187
0 0 1 0 0.432 0.382 0.348 0.315 0.282 0.260 0.243 0.227
0 0 1 1 0.501 0.445 0.407 0.369 0.331 0.306 0.287 0.268
0 1 0 0 0.544 0.485 0.444 0.404 0.363 0.336 0.316 0.295
0 1 0 1 0.605 0.541 0.497 0.454 0.408 0.379 0.356 0.333
0 1 1 0 0.656 0.589 0.542 0.496 0.448 0.416 0.392 0.367
0 1 1 1 0.709 0.640 0.589 0.540 0.489 0.455 0.430 0.403
1 0 0 0 0.743 0.672 0.620 0.570 0.516 0.481 0.454 0.426
1 0 0 1 0.790 0.717 0.663 0.611 0.555 0.517 0.489 0.460
1 0 1 0 0.830 0.754 0.700 0.646 0.558 0.549 0.520 0.489
1 0 1 1 0.871 0.794 0.738 0.682 0.623 0.583 0.552 0.520
1 1 0 0 0.897 0.819 0.762 0.706 0.645 0.604 0.572 0.540
1 1 0 1 0.934 0.856 0.798 0.740 0.677 0.635 0.602 0.569
1 1 1 0 0.967 0.888 0.829 0.770 0.706 0.663 0.630 0.595
1 1 1 1 1.000 0.920 0.860 0.801 0.736 0.692 0.658 0.622
DIP Switch Setting Multipliers
Table 3-1
